Motorola MVME714M多路复用器模块 PDF资料

1.产 品 资 料 介 绍：

Motorola MVME714M 多路复用器模块

产品概述

Motorola MVME714M 是一款基于 VMEbus 架构的多路复用器（Multiplexer, MUX）模块，用于 MVME714 系列单板计算机系统。该模块用于 集中管理和切换多个数字或模拟信号通道，将不同的输入信号选择性传输到 CPU 模块或其他处理单元，实现高效信号调度和数据管理。MVME714M 可与 MVME714 系列 CPU 模块及其他 VME 扩展模块协同工作，是工业自动化、测试测量和嵌入式实时控制系统的重要组件。

技术参数

• 总线接口：VMEbus 标准，支持 16/32 位数据传输

• 复用功能：

• 多路数字或模拟信号通道选择

• 可编程切换逻辑

• 支持同步或异步信号复用

• 控制功能：

• CPU 控制下的信号选择

• 支持中断和状态反馈

• 与其他模块的数据交互和总线控制兼容

• 兼容性：与 MVME714 系列 CPU 模块及 VME 扩展模块兼容

• 工作环境：工业级设计，抗干扰能力强，适应长期连续运行

应用场景

1. 工业自动化控制

• 多传感器数据集中管理，实现数字/模拟信号的高效调度。

2. 机床与运动控制系统

• 管理多个传感器或执行器通道，实现多轴控制与状态监控。

3. 实验室测试与测量系统

• 多通道信号采集、测试数据切换及实验设备接口管理。

4. 通信与嵌入式系统

• 多路信号数据复用，实现嵌入式通信节点的数据调度。

5. 能源与电力系统

• 对多个监测点或传感器信号进行集中选择与传输，实现自动化控制和监控。

Motorola  MVME5110-2263单板计算机 英文资料：

Motorola MVME714M multiplexer module

Product Overview

The Motorola MVME714M is a multiplexer (MUX) module based on the VMEbus architecture, used for the MVME714 series of single board computer systems. This module is used for centralized management and switching of multiple digital or analog signal channels, selectively transmitting different input signals to CPU modules or other processing units, achieving efficient signal scheduling and data management. MVME714M can work in conjunction with MVME714 series CPU modules and other VME expansion modules, and is an important component of industrial automation, testing and measurement, and embedded real-time control systems.

Technical Specifications

Bus interface: VMEbus standard, supports 16/32-bit data transmission

Reuse function:

Selection of multi-channel digital or analog signal channels

Programmable switching logic

Support synchronous or asynchronous signal reuse

Control function:

Signal selection under CPU control

Support interrupts and status feedback

Compatible with data exchange and bus control with other modules

Compatibility: Compatible with MVME714 series CPU modules and VME expansion modules

Work environment: Industrial grade design, strong anti-interference ability, suitable for long-term continuous operation

Application scenarios

industrial automation control

Centralized management of multi-sensor data to achieve efficient scheduling of digital/analog signals.

Machine Tool and Motion Control System

Manage multiple sensor or actuator channels to achieve multi axis control and status monitoring.

Laboratory Testing and Measurement System

Multi channel signal acquisition, testing data switching, and experimental equipment interface management.

Communication and Embedded Systems

Multiplexing of multiple signal data to achieve data scheduling for embedded communication nodes.

Energy and Power Systems

Centralize the selection and transmission of signals from multiple monitoring points or sensors to achieve automated control and monitoring.
