Motorola MVME333S-2控制器模块 PDF资料

1.产 品 资 料 介 绍：

Motorola MVME333S-2 控制器模块

产品概述

Motorola MVME333S-2 是一款基于 VMEbus 架构的嵌入式控制器模块，属于 MVME333 系列单板计算机。该模块集成了 CPU、内存、定时器及多种 I/O 接口，用于工业自动化、测试测量、通信系统及嵌入式实时控制场景。MVME333S-2 可作为系统的核心处理单元，提供可靠的计算和控制能力，同时与 VME 总线及其他扩展模块无缝协作。

技术参数

• 处理器：Motorola MC68040 或 MC68LC040（具体版本视型号而定）

• 内存：

• RAM：4 MB – 16 MB，可扩展

• ROM/Flash：256 KB – 2 MB，用于固件和引导程序

• NVRAM：带实时时钟功能

• 总线接口：VMEbus 标准，支持 16/32 位数据传输，A16/A24/A32 地址空间

• I/O 接口：

• 多路串行接口（RS-232/RS-422）

• 并行接口

• 定时器与看门狗

• 控制功能：

• 支持中断管理、DMA 数据传输

• 内置自检功能（BIT）

• 兼容性：支持 VxWorks、pSOS 等实时操作系统

• 工作环境：工业级设计，适应长时间连续运行

应用场景

1. 工业自动化与过程控制

• 控制生产线设备、PLC 系统及过程监控。

2. 机床与运动控制系统

• 多轴同步控制、脉冲输出和实时运动控制。

3. 测试与测量系统

• 数据采集、实验控制和仪器管理。

4. 通信系统与网络设备

• 电信交换节点、嵌入式通信控制器。

5. 能源与电力系统

• 发电设备、变电站控制和自动化管理。

6. 科研与仿真系统

• 实时嵌入式控制与实验仿真平台。

Motorola  MVME332XT 01-W3475B-02D总线控制器 英文资料：

Motorola MVME333S-2 Controller Module

Product Overview

Motorola MVME333S-2 is an embedded controller module based on the VMEbus architecture, belonging to the MVME333 series of single board computers. This module integrates CPU, memory, timer, and multiple I/O interfaces, and is used in industrial automation, testing and measurement, communication systems, and embedded real-time control scenarios. MVME333S-2 can serve as the core processing unit of the system, providing reliable computing and control capabilities, while seamlessly collaborating with VME bus and other expansion modules.

Technical Specifications

Processor: Motorola MC68040 or MC68LC040 (depending on the model)

Memory:

RAM：4 MB – 16 MB， scalable

ROM/Flash：256 KB – 2 MB， Used for firmware and bootloader

NVRAM: with real-time clock function

Bus interface: VMEbus standard, supports 16/32-bit data transmission, A16/A24/A32 address space

I/O interface:

Multi channel serial interface (RS-232/RS-422)

Parallel Interface

Timer and watchdog

Control function:

Support interrupt management and DMA data transfer

Built in self-test function (BIT)

Compatibility: Supports real-time operating systems such as VxWorks and pSOS

Work environment: Industrial grade design, suitable for long-term continuous operation

Application scenarios

Industrial Automation and Process Control

Control production line equipment, PLC system, and process monitoring.

Machine Tool and Motion Control System

Multi axis synchronous control, pulse output, and real-time motion control.

Testing and Measurement System

Data collection, experimental control, and instrument management.

Communication system and network equipment

Telecommunications switching nodes, embedded communication controllers.

Energy and Power Systems

Power generation equipment, substation control, and automation management.

Research and Simulation System

Real time embedded control and experimental simulation platform.
