Motorola MVME224A-1 01-W3588B动态内存模块 PDF资料

1.产 品 资 料 介 绍：

Motorola MVME224A-1 01-W3588B 动态内存模块

产品概述

Motorola MVME224A-1（型号 01-W3588B）是 VMEbus 架构下的动态内存扩展模块，专为 MVME224 系列单板计算机设计。该模块用于提供 高速动态随机存取存储器（DRAM），扩展系统的内存容量和数据处理能力，适合工业自动化、嵌入式控制和实时计算系统。MVME224A-1 支持 VME 总线与 CPU 模块无缝集成，保证系统在高负载和多任务环境下的可靠性能。

技术参数

• 内存类型：动态随机存储器（DRAM）

• 容量：典型 4 MB – 16 MB（可配置或根据版本不同）

• 接口：VMEbus 标准接口，支持 16/32 位数据总线

• 时序特性：高速存取，支持 CPU 的同步访问

• 电气特性：工业级设计，抗干扰能力强，带有电源保护

• 兼容性：与 MVME224 系列 CPU 模块兼容

• 工作环境：工业温度等级，适合长时间连续运行

应用场景

1. 工业自动化系统

• 扩展控制器的内存容量，用于复杂控制算法和数据缓存。

2. 嵌入式实时控制

• 支持多任务实时操作系统，提高系统计算能力和响应速度。

3. 数据采集与测试系统

• 用于高速数据存储和处理，满足科研和工业实验的需求。

4. 通信和网络设备

• 提供缓存和临时数据存储，提高数据交换速率和可靠性。

5. 军工与航空航天系统

• 用于嵌入式计算平台的内存扩展，保证长期稳定运行。

产品优势

• 高速动态存储：支持 CPU 高速访问，提高系统数据处理能力。

• 模块化扩展：可独立更换或升级，方便系统扩展。

• 可靠性高：工业级设计，抗干扰能力强，适合长期运行。

• 兼容性好：与 MVME224 系列 CPU 模块和 VMEbus 系统无缝配合。

• 维护方便：标准化模块设计，便于替换和升级。

Motorola  MVME224A-1 01-W3588B动态内存模块 英文资料：

Motorola MVME224A-1 01-W3588B Dynamic Memory Module

Product Overview

Motorola MVME224A-1 (model 01-W3588B) is a dynamic memory expansion module designed for the MVME224 series single board computers under the VMEbus architecture. This module is used to provide high-speed dynamic random access memory (DRAM), expand the system's memory capacity and data processing capabilities, and is suitable for industrial automation, embedded control, and real-time computing systems. MVME224A-1 supports seamless integration of VME bus and CPU module, ensuring reliable performance of the system in high load and multitasking environments.

Technical Specifications

Memory type: Dynamic Random Access Memory (DRAM)

Capacity: Typical 4 MB -16 MB (configurable or depending on version)

Interface: VMEbus standard interface, supporting 16/32-bit data bus

Timing characteristics: high-speed access, supporting synchronous access of CPU

Electrical characteristics: Industrial grade design, strong anti-interference ability, with power protection

Compatibility: Compatible with MVME224 series CPU modules

Working environment: Industrial temperature rating, suitable for long-term continuous operation

Application scenarios

Industrial automation system

Expand the memory capacity of the controller for complex control algorithms and data caching.

Embedded real-time control

Support multitasking real-time operating systems to improve system computing power and response speed.

Data Collection and Testing System

Used for high-speed data storage and processing, meeting the needs of scientific research and industrial experiments.

Communication and network equipment

Provide caching and temporary data storage to improve data exchange speed and reliability.

Military and Aerospace Systems

Used for memory expansion in embedded computing platforms to ensure long-term stable operation.

Product advantages

High speed dynamic storage: supports CPU high-speed access and improves system data processing capabilities.

Modular expansion: It can be independently replaced or upgraded, making it convenient for system expansion.

High reliability: Industrial grade design, strong anti-interference ability, suitable for long-term operation.

Good compatibility: seamlessly integrates with MVME224 series CPU modules and VMEbus systems.

Easy maintenance: Standardized module design for easy replacement and upgrade.

Motorola MVME224A-1 01-W3588B动态内存模块 产品展示
