Motorola MVME 333-2 01-W3503B-06E通信模块 PDF资料

1.产 品 资 料 介 绍：

Motorola MVME 333-2 01-W3503B-06E 通信模块

产品概述

Motorola MVME 333-2 是一款基于 VMEbus 总线架构的通信接口模块，型号 01-W3503B-06E 表示该产品的具体版本号和硬件修订。该模块主要用于在 VME 系统中实现多种通信功能，包括 串行通信、外设互联及设备间数据交换。它能够与 MVME 系列 CPU 板协同工作，常见于工业自动化、军事电子和能源控制等高可靠性应用场合。

技术参数

• 总线标准：兼容 VMEbus 规范，支持与主 CPU 模块和 I/O 模块互联

• 通信接口：

• 多路异步/同步串行通信接口（常见 RS-232/RS-422/RS-485）

• 支持全双工/半双工模式

• 传输速率：可配置波特率，满足低速控制与中速数据传输需求

• 处理能力：内置通信控制逻辑，可减轻主 CPU 数据处理负担

• 兼容性：适配 Motorola MVME 系列（如 MVME-1300、MVME-2300 等 CPU 板）

• 可靠性：工业级设计，具备电气隔离与抗干扰能力

应用场景

1. 工业自动化

• 用于数控机床、生产线 PLC 控制系统，实现控制器与传感器、执行器的通信。

2. 电力与能源

• 在变电站、发电厂数据采集与监控系统中，用于串口设备接入与信息传输。

3. 国防与航空航天

• 应用于飞控系统、雷达与任务计算平台，实现模块间可靠串行通信。

4. 通信系统

• 在通信基站、交换机中作为外设通信接口模块，保障设备间数据交换。

5. 科研与测试设备

• 在实验仪器、数据采集平台中实现多串口接入与测试模块的同步通信。

产品优势

• 多通道设计：支持多路串行接口，便于系统扩展。

• 高可靠性：工业级电气与机械设计，保证长时间稳定运行。

• 减轻主机负载：通信处理由模块完成，释放 CPU 运算资源。

• 系统兼容性强：与 Motorola MVME 系列 CPU 和 I/O 板配合良好。

• 应用成熟：在工业、军工、能源领域有广泛使用案例。

Motorola  MVME 333-2 01-W3503B-06E通信模块 英文资料：

Motorola MVME 333-2 01-W3503B-06E Communication Module

Product Overview

Motorola MVME 333-2 is a communication interface module based on the VMEbus architecture, with model 01-W3503B-06E indicating the specific version number and hardware revision of the product. This module is mainly used to implement various communication functions in the VME system, including serial communication, peripheral interconnection, and data exchange between devices. It can work in conjunction with MVME series CPU boards and is commonly used in high reliability applications such as industrial automation, military electronics, and energy control.

Technical Specifications

Bus standard: compatible with VMEbus specification, supporting interconnection with main CPU module and I/O module

Communication interface:

Multi channel asynchronous/synchronous serial communication interface (commonly known as RS-232/RS-422/RS-485)

Supports full duplex/half duplex mode

Transmission rate: configurable baud rate to meet low-speed control and medium speed data transmission requirements

Processing capability: Built in communication control logic, which can reduce the data processing burden on the main CPU

Compatibility: Compatible with Motorola MVME series (such as MVME-1300, MVME-2300, etc. CPU boards)

Reliability: Industrial grade design with electrical isolation and anti-interference capabilities

Application scenarios

Industrial Automation

Used for CNC machine tools and production line PLC control systems to achieve communication between controllers, sensors, and actuators.

Electricity and Energy

Used for serial device access and information transmission in data acquisition and monitoring systems of substations and power plants.

Defense and Aerospace

Applied to flight control systems, radar, and task computing platforms to achieve reliable serial communication between modules.

communication system

As a peripheral communication interface module in communication base stations and switches, it ensures data exchange between devices.

Research and testing equipment

Implement synchronous communication between multi serial port access and testing modules in experimental instruments and data acquisition platforms.

Product advantages

Multi channel design: Supports multiple serial interfaces for easy system expansion.

High reliability: Industrial grade electrical and mechanical design ensures long-term stable operation.

Reduce host load: Communication processing is completed by modules, freeing up CPU computing resources.

Strong system compatibility: It works well with Motorola MVME series CPUs and I/O boards.

Mature application: widely used in industrial, military, and energy fields.

Motorola MVME 333-2 01-W3503B-06E通信模块 产品展示
