Motorola MVME-327A总线适配器 PDF资料

1.产 品 资 料 介 绍：

Motorola MVME-327A 总线适配器

产品概述

Motorola MVME-327A 是一款基于 VMEbus 架构的总线适配器模块，属于 Motorola MVME 系列扩展与接口类产品。它的主要作用是为 VME 总线系统与外部设备或其他总线系统提供数据交互和信号转换能力。作为系统中的接口桥接模块，MVME-327A 通常与 CPU 模块（如 MVME-1300/2300/2600 系列）配合使用，为嵌入式计算与实时控制提供扩展 I/O 通道和更强的兼容性。

技术参数

• 总线标准：完全兼容 VMEbus 规范（VME64 可向下兼容）

• 功能定位：总线适配与信号转换，作为主控制器和外设间的桥接单元

• 接口能力：提供标准化 VMEbus 信号接口，并支持部分定制信号扩展

• 电气特性：符合工业环境下的电气隔离与抗干扰要求

• 兼容性：可与 Motorola MVME 系列 CPU 控制模块无缝对接

• 工作环境：工业级工作温度范围，适应长期运行与高可靠性场景

应用场景

1. 工业自动化

• 在复杂生产线上，用于将 VME 控制系统与不同类型的 I/O 模块或现场总线设备连接。

2. 电力与能源系统

• 在变电站自动化和电力监控中，用于接入外部监控单元或数据采集模块。

3. 国防与航空电子

• 用于将 VME 平台嵌入雷达、导航或任务控制系统中，实现跨总线的数据交换。

4. 通信设备

• 在通信基站或交换设备中，作为主控制器与外设数据通道的桥梁。

5. 实验与科研装置

• 用于科研仪器和实验设备中，确保主控系统与测试模块之间的高速可靠通信。

产品优势

• 强兼容性：完全遵循 VMEbus 标准，能适配多种 CPU 模块和外设。

• 高可靠性：工业级设计，保证在电磁干扰和恶劣环境下的稳定运行。

• 灵活扩展：支持多种总线设备接入，扩展系统功能。

• 长期支持：广泛应用于军工、能源和工业场合，生命周期长，维护便利。

• 模块化设计：可与其他 MVME 系列控制器、I/O 板卡组合，形成完整的嵌入式解决方案。

Motorola  MVME 2301 01-W3345F-01H控制器模块 英文资料：

Motorola MVME-327A Bus Adapter

Product Overview

Motorola MVME-327A is a bus adapter module based on the VMEbus architecture, belonging to the Motorola MVME series of extension and interface products. Its main function is to provide data exchange and signal conversion capabilities between the VME bus system and external devices or other bus systems. As an interface bridging module in the system, MVME-327A is usually used in conjunction with CPU modules (such as MVME-1300/2300/2600 series) to provide extended I/O channels and stronger compatibility for embedded computing and real-time control.

Technical Specifications

Bus standard: Fully compatible with VMEbus specification (VME64 is backward compatible)

Functional positioning: Bus adaptation and signal conversion, serving as a bridging unit between the main controller and peripherals

Interface capability: Provide standardized VMEbus signal interface and support some customized signal extensions

Electrical characteristics: meet the requirements of electrical isolation and anti-interference in industrial environments

Compatibility: Seamless integration with Motorola MVME series CPU control modules

Working environment: Industrial grade working temperature range, suitable for long-term operation and high reliability scenarios

Application scenarios

Industrial Automation

Used to connect VME control systems with different types of I/O modules or fieldbus devices on complex production lines.

Power and Energy Systems

In substation automation and power monitoring, it is used to connect external monitoring units or data acquisition modules.

Defense and Aerospace Electronics

Used to embed the VME platform into radar, navigation, or task control systems to achieve cross bus data exchange.

communication equipment

As a bridge between the main controller and peripheral data channels in communication base stations or switching equipment.

Experimental and scientific research equipment

Used in scientific research instruments and experimental equipment to ensure high-speed and reliable communication between the main control system and the testing module.

Product advantages

Strong compatibility: fully compliant with the VMEbus standard, able to adapt to various CPU modules and peripherals.

High reliability: Industrial grade design ensures stable operation in electromagnetic interference and harsh environments.

Flexible Expansion: Supports multiple bus device access and expands system functionality.

Long term support: widely used in military, energy, and industrial applications, with a long lifecycle and easy maintenance.

Modular design: can be combined with other MVME series controllers and I/O boards to form a complete embedded solution.
