SRM50-FPA0-K21编码器 PDF资料

1.产 品 资 料 介 绍：

SICK SRM50-FPA0-K21 编码器简介

SICK SRM50-FPA0-K21 属于 SRM50 系列的小型增量式旋转编码器，常用于设备速度监测、位置反馈及电机控制等场合。该系列以结构紧凑、信号稳定、适应性强而受到工业自动化领域的广泛使用。

主要特性

• 结构紧凑
  50 mm 外径设计，适合空间受限的装机环境。

• 增量式输出
  提供标准 A/B/Z 三通道脉冲，适合方向识别、基准点定位等控制需求。

• 高精度脉冲分辨率
  不同订货代码对应不同 PPR，SRM50-FPA0-K21 一般为中高分辨率配置，适合速度与位置反馈。

• 坚固耐用
  金属外壳设计，耐冲击与震动，适用于普通工业环境。

• 安装方式灵活
  采用同步法兰（Synchro flange），安装定位简单可靠。

• 多种电气接口可用
  根据 K21 配置，通常为推挽输出或差分输出（具体以铭牌为准），便于接入 PLC、驱动器等设备。

典型技术参数（通用 SRM50 系列参考）

若你需要，我也可以根据你手上的铭牌参数给你做专属版本。

• 外径：50 mm

• 轴类型：实心轴

• 轴径：一般为 6 mm（以型号为准）

• 输出信号：A / B / Z 增量脉冲

• 输出电路：推挽或差分

• 工作电压：通常 4.5…30 V DC

• 分辨率范围：几十到数千 PPR（K21 对应固定配置）

• 工作温度：约 –20…+85 °C

• 防护等级：常见为 IP65（视具体版本）

SRM50-FPA0-K21编码器 英文介绍

Introduction to SICK SRM50-FPA0-K21 Encoder

SICK SRM50-FPA0-K21 belongs to the SRM50 series of small incremental rotary encoders, commonly used in equipment speed monitoring, position feedback, and motor control applications. This series is widely used in the field of industrial automation due to its compact structure, stable signal, and strong adaptability.

Key Features

compact structure

Designed with an outer diameter of 50 mm, suitable for installation environments with limited space.

Incremental output

Provide standard A/B/Z three channel pulses, suitable for control requirements such as direction recognition and reference point positioning.

High precision pulse resolution

Different ordering codes correspond to different PPRs. SRM50-FPA0-K21 is generally a medium to high resolution configuration, suitable for speed and position feedback.

sturdy and durable

Metal shell design, resistant to impact and vibration, suitable for ordinary industrial environments.

Flexible installation method

Adopting Synchro flange, installation and positioning are simple and reliable.

Multiple electrical interfaces are available

According to the K21 configuration, it is usually a push-pull output or differential output (depending on the nameplate), which is convenient for connecting to devices such as PLCs and drivers.

Typical Technical Parameters (Reference for General SRM50 Series)

If you need, I can also make a customized version for you based on the parameters on the nameplate you have.

Outer diameter: 50 mm

Axis type: solid axis

Shaft diameter: generally 6 mm (depending on the model)

Output signal: A/B/Z incremental pulse

Output circuit: push-pull or differential

Working voltage: usually 4.5... 30 V DC

Resolution range: tens to thousands of PPR (K21 corresponds to fixed configuration)

Working temperature: approximately -20...+85 ° C

Protection level: commonly IP65 (depending on specific version)

SRM50-FPA0-K21编码器 产品展示
