1326AB-B520F-M 伺服电机  PDF资料

1.产 品 资 料 介 绍：

AB 1326AB-B520F-M 伺服电机简介

1326AB-B520F-M 属于 Allen-Bradley 1326AB 系列的一款交流伺服电机，专为高性能运动控制应用打造，适用于配合 Kinetix、1394 等驱动平台使用。该系列以稳定扭矩输出、良好加速度表现和较宽的速度范围而受到工业用户青睐。

核心特性

• 高动态响应
  采用稀土永磁电机结构，使电机在加减速过程中具备敏捷的扭矩变化能力。

• 可靠的编码器反馈
  配备标准高分辨率反馈装置，确保驱动系统可精准控制位置、速度与扭矩。

• 坚固的机械结构
  铝合金机壳搭配高强度轴承系统，可应对连续运行与重载冲击。

• 宽速度与扭矩范围
  适合中高转速工作环境，兼具持续扭矩输出与短时峰值扭矩能力。

• 优良的散热能力
  结构紧凑、热设计合理，可在高负载场景下保持运行稳定。

典型参数范围（按1326AB系列通用规格给出）

由于不同尾缀型号会有细微差异，下列为该系列常见参数区间，与你的型号 B520F-M 接近：

• 额定功率：约 2~4 kW

• 额定转速：一般在 1500–3000 rpm 范围

• 峰值转速：可达 4500 rpm 以上

• 额定扭矩：约 10–20 N·m（具体视子型号而定）

• 峰值扭矩：可达额定扭矩的 3 倍左右

• 绝缘等级：F 级

• 防护等级：常见为 IP54

 1326AB-B520F-M 伺服电机  英文介绍

Introduction to AB 1326AB-B520F-M servo motor

1326AB-B520F-M is an AC servo motor belonging to the Allen Bradley 1326AB series, designed for high-performance motion control applications and suitable for use with driver platforms such as Kinetix and 1394. This series is favored by industrial users for its stable torque output, good acceleration performance, and wide speed range.

Core Features

High dynamic response

Adopting a rare earth permanent magnet motor structure, the motor has agile torque variation ability during acceleration and deceleration processes.

Reliable encoder feedback

Equipped with a standard high-resolution feedback device to ensure precise control of position, speed, and torque in the drive system.

Robust mechanical structure

Aluminum alloy casing combined with high-strength bearing system can cope with continuous operation and heavy load impact.

Wide speed and torque range

Suitable for medium to high speed working environments, with both continuous torque output and short-term peak torque capability.

Excellent heat dissipation capability

Compact structure, reasonable thermal design, can maintain stable operation in high load scenarios.

Typical parameter range (given according to the general specifications of 1326AB series)

Due to slight differences in suffix models, the following are common parameter ranges for this series, which are similar to your model B520F-M:

Rated power: approximately 2-4 kW

Rated speed: generally in the range of 1500-3000 rpm

Peak speed: up to 4500 rpm or above

Rated torque: approximately 10-20 N · m (depending on the sub model)

Peak torque: up to about 3 times the rated torque

Insulation level: F level

Protection level: commonly IP54

1326AB-B520F-M 伺服电机  产品展示
