AEG MODICON SCU150输入输出模块 PDF资料

1.产 品 资 料 介 绍：

AEG Modicon SCU150 输入输出模块 — 模块概述

SCU150 是 AEG Modicon 系列中用于现场信号集中处理的 I/O 控制单元，它主要承担底层设备与控制系统之间的桥梁作用，将各种开关量、模拟量信号进行收集、转换与分发，为自动化站点提供稳定的 I/O 管理能力。

核心特性

1. 集成式 I/O 架构

模块将输入与输出资源整合在同一硬件上，减少额外扩展卡件，有利于构建紧凑的控制柜结构。

2. 实时数据采集

具备快速扫描与数据缓冲能力，能够持续监测来自传感器、按钮、执行器的信号，实现实时的状态更新与控制。

3. 工业级稳定性

SCU150 以耐干扰设计著称，能够适应电气噪声较强的环境，确保在长期运行中保持稳定的 I/O 通讯能力。

4. 与 Modicon 主控制架构兼容

可无缝集成到多种 Modicon 控制系统中，用作前端 I/O 站点或子控制单元，提高系统整体灵活度。

输入/输出能力说明

虽然不同批次参数可能略有差异，但典型功能包括：

• 数字输入：采集现场的开关量状态，如限位信号、保护触点等

• 数字输出：驱动继电器、指示指灯、控制小型电磁阀等

• 模拟输入选配：可选支持电压/电流信号输入，用于温度、压力、位移等过程量

• 隔离保护：输入输出具备通道隔离，提升系统安全性与抗干扰能力

AEG MODICON SCU150输入输出模块 英文介绍

AEG Modicon SCU150 Input/Output Module - Module Overview

SCU150 is an I/O control unit used for centralized on-site signal processing in the AEG Modicon series. It mainly serves as a bridge between underlying devices and control systems, collecting, converting, and distributing various switch and analog signals to provide stable I/O management capabilities for automation sites.

Core Features

1. Integrated I/O architecture

The module integrates input and output resources on the same hardware, reducing the need for additional expansion cards and facilitating the construction of a compact control cabinet structure.

2. Real time data collection

Capable of fast scanning and data buffering, able to continuously monitor signals from sensors, buttons, and actuators, achieving real-time status updates and control.

3. Industrial grade stability

SCU150 is known for its anti-interference design, which can adapt to environments with strong electrical noise and ensure stable I/O communication capabilities during long-term operation.

4. Compatible with Modicon main control architecture

It can be seamlessly integrated into various Modicon control systems and used as a front-end I/O station or sub control unit, improving the overall flexibility of the system.

Input/output capability description

Although there may be slight differences in parameters between different batches, typical features include:

Digital input: Collect on-site switch status, such as limit signals, protective contacts, etc

Digital outputs: drive relays, indicator lights, control small solenoid valves, etc

Analog input optional: optional support for voltage/current signal input, used for process variables such as temperature, pressure, displacement, etc

Isolation protection: Input and output have channel isolation to enhance system security and anti-interference capability

AEG MODICON SCU150输入输出模块 产品展示
