PolyScience 5360T11A110C 涡轮泵循环冷却器 PDF资料
PolyScience 5360T11A110C 是5000系列的一款带涡轮泵的循环冷却器，适用于需要较高输出压力的闭路循环冷却应用，常用于实验室和轻工业设备的温控配套。
产品特点
配备涡轮泵，最大压力可达100psi，适合管路较长或内部通路较窄的闭环系统。
温度控制范围-10°C至+70°C，温度稳定性±0.1°C，控温精度较高。
带加热功能，可在低于环境温度或高于环境温度的场景下工作。
数字控制面板，可进行设定值调节，并设有温度、流量和压力报警功能。
美国制造，以OEM备件形式流通于二手设备市场。
产品参数
品牌：PolyScience。
型号：5360T11A110C，所属系列5000 Series。
压缩机功率：1/3 HP。
电源：120V，60Hz，单相，13.5A。
流量与压力：最大流量3.5 GPM（13.2 L/min），最大压力100 PSI（6.9 bar）。
应用领域
激光设备的闭环冷却配套。
生物技术与分子诊断设备中的温控流体循环。
分析仪器（如光谱仪、旋转蒸发仪）的冷却配套。
夹套反应容器及生物制药流程的温控。
半导体制造设备及二手设备翻新中的冷却部件替换。
结尾
PolyScience 5360T11A110C 凭借涡轮泵的高压输出能力和±0.1°C的控温精度，在需要闭路循环冷却的各类实验室和工业设备中具有较高的配套价值，也是二手设备市场中值得关注的冷却备件型号。
PolyScience 5360T11A110C 涡轮泵循环冷却器 英文介绍
PolyScience 5360T11A110C is a 5000 series circulating cooler with a turbo pump, suitable for closed-loop cooling applications that require high output pressure. It is commonly used for temperature control matching in laboratories and light industrial equipment.
Product Features
Equipped with a turbo pump, the maximum pressure can reach 100psi, suitable for closed-loop systems with long pipelines or narrow internal passages.
The temperature control range is from -10 ° C to+70 ° C, with a temperature stability of ± 0.1 ° C and high temperature control accuracy.
Equipped with heating function, it can work in scenarios below or above ambient temperature.
The digital control panel can adjust the set value and is equipped with temperature, flow, and pressure alarm functions.
Made in the United States and circulated in the second-hand equipment market as OEM spare parts.
Product Parameters
Brand: PolyScience.
Model: 5360T11A110C, belonging to the 5000 Series.
Compressor power: 1/3 HP.
Power supply: 120V, 60Hz, single-phase, 13.5A.
Flow and pressure: Maximum flow rate of 3.5 GPM (13.2 L/min), maximum pressure of 100 PSI (6.9 bar).
Application Areas
Closed loop cooling matching for laser equipment.
Temperature controlled fluid circulation in biotechnology and molecular diagnostic equipment.
Cooling equipment for analytical instruments such as spectrometers and rotary evaporators.
Temperature control of jacketed reaction vessels and biopharmaceutical processes.
Replacement of cooling components in semiconductor manufacturing equipment and second-hand equipment refurbishment.
ending
PolyScience 5360T11A110C has high matching value in various laboratory and industrial equipment that require closed-loop cooling due to its high-pressure output capability of turbo pumps and temperature control accuracy of ± 0.1 ° C. It is also a cooling spare part model worth paying attention to in the second-hand equipment market.
PolyScience 5360T11A110C 涡轮泵循环冷却器 产品图片
