Yaskawa SGM7D-1C1FC-TE12 直驱伺服电机 PDF资料
Yaskawa SGM7D-1C1FC-TE12 是安川电机Sigma-7系列的一款带铁芯外转子直驱伺服电机，适用于需要高扭矩、高精度和高刚性的应用场景。
产品特点
直驱结构，无需减速机，消除背隙和振动，实现高精度定位。
搭载24位高分辨率编码器，提供出色的控制精度。
高惯性设计，可承载较大的负载转动惯量。
拥有大口径中空孔，方便布线及配管，节省安装空间。
配套Σ-7系列FT82或FT83型专用驱动器，普通旋转型伺服驱动器无法驱动。
产品参数
品牌：安川电机。
系列：Sigma-7 SGM7D系列。
类型：带铁芯外转子直驱伺服电机。
配套驱动器：Σ-7系列FT82或FT83型专用驱动器。
产地：日本制造。
应用领域
半导体制造设备中的高精度定位与承载。
液晶涂布机、配光膜喷墨装置等电子制造设备。
划线机等需要大负载承载的工业机械。
分度台、定位仪等需要高精度角度控制的场景。
医疗设备、光学测试等高精密仪器领域。
结尾
Yaskawa SGM7D-1C1FC-TE12 作为Sigma-7系列的直驱伺服电机，通过消除机械传动环节，为高精度、高刚性应用提供了理想的驱动解决方案，在半导体及电子制造设备等领域具有重要应用价值。
Yaskawa SGM7D-1C1FC-TE12 直驱伺服电机 英文介绍
Yaskawa SGM7D-1CFC-TE12 is a direct drive servo motor with an iron core outer rotor from Yaskawa Electric's Sigma-7 series, suitable for applications that require high torque, high precision, and high rigidity.
Product Features
Direct drive structure, without the need for a gearbox, eliminates backlash and vibration, achieving high-precision positioning.
Equipped with a 24 bit high-resolution encoder, it provides excellent control accuracy.
High inertia design, capable of carrying large loads with rotational inertia.
Featuring large-diameter hollow holes for easy wiring and piping, saving installation space.
Equipped with ∑ -7 series FT82 or FT83 special drives, ordinary rotary servo drives cannot drive.
Product Parameters
Brand: Yaskawa Electric.
Series: Sigma-7 SGM7D series.
Type: Direct drive servo motor with iron core outer rotor.
Supporting driver: ∑ -7 series FT82 or FT83 dedicated driver.
Origin: Made in Japan.
Application Areas
High precision positioning and load-bearing in semiconductor manufacturing equipment.
Electronic manufacturing equipment such as LCD coating machines, light distribution film inkjet devices, etc.
Industrial machinery such as marking machines that require large load carrying capacity.
Scenarios that require high-precision angle control, such as indexing tables and locators.
In the field of high-precision instruments such as medical equipment and optical testing.
ending
Yaskawa SGM7D-1CFC-TE12, as a direct drive servo motor of the Sigma-7 series, provides an ideal driving solution for high-precision and high rigidity applications by eliminating mechanical transmission links. It has important application value in fields such as semiconductor and electronic manufacturing equipment.
Yaskawa SGM7D-1C1FC-TE12 直驱伺服电机 产品图片
