Edwards PT41-SZ-200 涡轮分子泵 PDF资料
1.产 品 资 料 介 绍：
Edwards PT41-SZ-200 涡轮分子泵
该型号为Edwards STP系列涡轮分子泵，对应泵型为STP-A2203C2，用于高真空环境的快速建立与维持。
产品特点
部件编号PT41-SZ-200，对应泵型STP-A2203C2。
采用磁悬浮轴承设计，运行平稳，振动和噪音极低。
无油运行结构，提供高洁净度真空环境。
采用多级涡轮叶片结构，压缩比高，极限真空稳定。
结构紧凑，便于集成到各类真空系统中。
适用于物理气相沉积、化学气相沉积等薄膜制备工艺。
适用于质谱分析、表面科学等科研实验场景。
具备标准真空法兰接口，适配主流真空腔体。
兼容标准真空系统控制协议。
该型号在二手市场中可作为维修备件采购。
核心参数
制造商：Edwards。
部件编号：PT41-SZ-200。
对应泵型：STP-A2203C2。
产地：英国。
产品状态：二手市场流通品。
总结
Edwards PT41-SZ-200（STP-A2203C2）是一款高真空涡轮分子泵，以无油洁净、低振动和紧凑结构为核心优势，适用于半导体薄膜制备及科研分析等对真空环境要求较高的场景。
Edwards PT41-SZ-200 涡轮分子泵 英文介绍
Edwards PT41-SZ-200 Turbomolecular Pump
This model is Edwards STP series turbo molecular pump, corresponding to pump type STP-A2203C2, used for rapid establishment and maintenance of high vacuum environments.
Product Features
Part number PT41-SZ-200, corresponding to pump type STP-A2203C2.
Designed with magnetic levitation bearings, it runs smoothly with extremely low vibration and noise.
Oil free operating structure, providing a high cleanliness vacuum environment.
Adopting a multi-stage turbine blade structure, with high compression ratio and extreme vacuum stability.
Compact structure, easy to integrate into various vacuum systems.
Suitable for thin film preparation processes such as physical vapor deposition and chemical vapor deposition.
Suitable for scientific research experimental scenarios such as mass spectrometry analysis and surface science.
Equipped with standard vacuum flange interface, compatible with mainstream vacuum chambers.
Compatible with standard vacuum system control protocols.
This model can be purchased as a maintenance spare part in the second-hand market.
Core parameters
Manufacturer: Edwards.
Part number: PT41-SZ-200.
Corresponding pump type: STP-A2203C2.
Origin: United Kingdom.
Product status: Second hand market circulation goods.
Summary
Edwards PT41-SZ-200 (STP-A2203C2) is a high vacuum turbo molecular pump with the core advantages of oil-free cleanliness, low vibration, and compact structure. It is suitable for semiconductor thin film preparation and scientific research analysis, which require high vacuum environment.
Edwards PT41-SZ-200 涡轮分子泵 产品图片
