DS200ACNAG1A 接口卡 PDF资料
1.产 品 资 料 介 绍：
DS200ACNAG1A 是通用电气为 Speedtronic Mark V 涡轮控制系统设计的 ARCNET 通信接口卡，负责控制器与上位机之间的实时数据交换。
产品特点
采用 ARCNET 令牌环协议，通信速率 2.5 Mbps。
配备 2 个 BNC 母头接口，支持总线级联与冗余配置。
板载 6 针垂直端子，用于电源与诊断信号连接。
集成两个通信继电器，用于状态指示与报警输出。
采用片上变压器耦合与差分曼彻斯特编码，抗干扰能力强。
支持 0~20 dB 动态增益补偿，可适应同轴电缆老化场景。
内置可恢复保险丝与 TVS 浪涌吸收，可承受 2kV 突发干扰。
支持 DIP 开关在线修改节点地址，无需断电。
即插即用设计，更换后无需重新下载逻辑，平均修复时间小于 3 分钟。
适配 Mark V 三重冗余架构，满足电厂关键控制要求。
产品参数
通信协议：ARCNET 2.5 Mbps 令牌环。
接口：2×BNC 母头 + 6-pin 垂直端子。
隔离耐压：1500V AC，1 分钟。
工作温度：-40℃~+85℃。
最大网段长度：≤4 英里（2.5 Mbps 时）。
结尾
DS200ACNAG1A 是 GE Mark V 系统的专用 ARCNET 通信卡，以高可靠性、抗干扰能力和即插即用特性为核心优势，适用于燃气轮机、蒸汽轮机等发电设备的控制通信场景
DS200ACNAG1A 接口卡 英文介绍
DS200ACNAG1A is an ARCNET communication interface card designed by General Electric for the Speedtronic Mark V turbine control system, responsible for real-time data exchange between the controller and the upper computer.
Product Features
Adopting ARCNET token ring protocol, with a communication speed of 2.5 Mbps.
Equipped with 2 BNC female interfaces, supporting bus cascading and redundant configuration.
Onboard 6-pin vertical terminal for power and diagnostic signal connection.
Integrate two communication relays for status indication and alarm output.
With on-chip transformer coupling and differential Manchester coding, it has strong anti-interference ability.
Supports dynamic gain compensation of 0-20 dB, suitable for aging scenarios of coaxial cables.
Built in recoverable fuse and TVS surge absorption, capable of withstanding 2kV sudden interference.
Support DIP switch online modification of node address without power outage.
Plug and play design, no need to re download logic after replacement, with an average repair time of less than 3 minutes.
Adapt to Mark V triple redundant architecture to meet critical control requirements of power plants.
Product Parameters
Communication protocol: ARCNET 2.5 Mbps token ring.
Interface: 2 x BNC female head+6-pin vertical terminal.
Isolation withstand voltage: 1500V AC, 1 minute.
Working temperature: -40 ℃~+85 ℃.
Maximum network segment length: ≤ 4 miles (at 2.5 Mbps).
ending
DS200ACNAG1A is a dedicated ARCNET communication card for GE Mark V system, with high reliability, anti-interference ability, and plug and play characteristics as its core advantages, suitable for control communication scenarios of power generation equipment such as gas turbines and steam turbines
DS200ACNAG1A 接口卡 产品图片
