TEL 5044-000063-12 印刷电路板 PDF资料
1.产 品 资 料 介 绍：
TEL 5044-000063-12 印刷电路板是东京电子相关设备中的专用组件，用于电路互连与信号传输。
产品特点
表面覆盖阻焊层，保护线路防短路。
布设元器件焊盘，支持SMD或通孔元件组装。
边缘设金手指或连接器接口，便于板间插接。
板面印有位号与丝印标识，方便装配与维修。
采用FR-4基材，电气性能稳定。
板厚与铜厚按载流需求设计。
支持多层布线，实现复杂电路连接。
表面处理兼容无铅焊接工艺。
定位孔设计符合标准机箱安装规范。
适用于半导体设备、工控系统等领域。
产品参数
基材：FR-4。
层数：多层板。
表面处理：沉金或OSP。
工艺兼容：回流焊或波峰焊。
工作温度：工业级。
结尾
TEL 5044-000063-12 是一款专用工业级PCB，工艺兼容性好，适用于半导体及工控设备。
TEL 5044-000063-12 printed circuit board is a specialized component used in Tokyo electronics related equipment for circuit interconnection and signal transmission.
Product Features
The surface is covered with a solder mask layer to protect the circuit from short circuits.
Install component solder pads to support SMD or through-hole component assembly.
The edge is equipped with gold fingers or connector interfaces for easy insertion between boards.
The board is printed with tag numbers and silk screen markings for easy assembly and maintenance.
Using FR-4 substrate, the electrical performance is stable.
The plate thickness and copper thickness are designed according to the current carrying requirements.
Support multi-layer wiring to achieve complex circuit connections.
Surface treatment compatible with lead-free soldering process.
The positioning hole design complies with the standard chassis installation specifications.
Suitable for fields such as semiconductor equipment and industrial control systems.
Product Parameters
Substrate: FR-4.
Number of layers: multi-layer board.
Surface treatment: immersion gold or OSP.
Process compatibility: reflow soldering or wave soldering.
Working temperature: industrial grade.
ending
TEL 5044-000063-12 is a specialized industrial grade PCB with good process compatibility, suitable for semiconductor and industrial control equipment.
