GEOIF6V0 528-5585 印刷电路板 PDF资料
1.产 品 资 料 介 绍：
GEOIF6V0 528-5585 印刷电路板是一款面向电子设备内部连接的定制化PCB组件，适用于需要稳定信号传输的电路系统。
产品特点
表面覆盖标准阻焊层，保护线路并防短路。
布设元器件焊盘和连接器焊盘，支持贴装与安装。
兼容表面贴装工艺，适配自动化贴片流程。
边缘连接器区域适配公头插针或母头插座。
连接器焊盘可分布于单面或双面。
板边预留安装槽或孔位，便于对接固定。
采用FR-4等绝缘基材，电气绝缘性能良好。
可通过载具支撑实现批量生产与分离。
连接器可选装护罩，提供额外物理防护。
适用于工业控制、通信设备、仪器仪表等领域。
产品参数
基材：FR-4玻璃纤维环氧树脂。
表面处理：阻焊层加焊盘镀层。
层数：单面或双面。
工艺兼容：支持回流焊等SMT工艺。
工作温度：-20℃~85℃。
结尾
GEOIF6V0 528-5585 是一款常规工业级PCB，工艺兼容性良好，适用于多种电子设备的电路互联场景。
GEOIF6V0 528-5585 printed circuit board is a customized PCB component designed for internal connections in electronic devices, suitable for circuit systems that require stable signal transmission.
Product Features
The surface is covered with a standard solder mask layer to protect the circuit and prevent short circuits.
Install component pads and connector pads to support mounting and installation.
Compatible with surface mount technology and adaptable to automated SMT processes.
The edge connector area is compatible with male pins or female sockets.
The connector pads can be distributed on one or both sides.
Reserved installation slots or holes on the edge of the board for easy docking and fixation.
Using insulation substrates such as FR-4, the electrical insulation performance is good.
Mass production and separation can be achieved through vehicle support.
The connector can be equipped with a protective cover to provide additional physical protection.
Suitable for industrial control, communication equipment, instrumentation and other fields.
Product Parameters
Substrate: FR-4 glass fiber epoxy resin.
Surface treatment: solder mask layer with solder pad coating.
Layers: single-sided or double-sided.
Process compatibility: Supports SMT processes such as reflow soldering.
Working temperature: -20 ℃~85 ℃.
ending
GEOIF6V0 528-5585 is a conventional industrial grade PCB with good process compatibility, suitable for circuit interconnection scenarios of various electronic devices.
