YASKAWA SGMAH-01B1F41 伺服电机 PDF资料
1.产 品 资 料 介 绍：
YASKAWA SGMAH-01B1F41 伺服电机
YASKAWA SGMAH-01B1F41 是安川电机Sigma-II系列的一款交流伺服电机，需搭配同系列的SGDH伺服驱动器使用。以下是其核心特点与关键参数。
产品特点
属于安川Sigma-II系列，适配SGDH系列驱动器。
额定功率100W，适用于中小负载场景。
额定转速3000 r/min，最高转速5000 r/min，动态响应快。
额定扭矩0.318 N·m，峰值扭矩0.96 N·m。
编码器类型需以实物铭牌标注为准，有绝对值或增量式两种可能。
防护等级IP55（轴伸处除外），具备防尘防水能力。
部分型号带24V DC保持制动器，选型时需确认实物是否配备。
采用带键槽的直轴设计，便于机械连接。
重量约0.62kg（不带制动器），结构紧凑。
绝缘等级为Class B。
产品参数品牌：YASKAWA（安川电机）
型号：SGMAH-01B1F41
产品系列：Sigma-II
额定功率：100W
额定电压：100V AC
总结
YASKAWA SGMAH-01B1F41 是Sigma-II系列伺服电机，功率100W，电压100V级，需配套SGDH驱动器使用
YASKAWA SGMAH-01B1F41 伺服电机 英文介绍
YASKAWA SGMAH-01B1F41 servo motor
YASKAWA SGMAH-01B1F41 is an AC servo motor of Yaskawa Electric's Sigma II series, which needs to be used in conjunction with SGDH servo drives of the same series. The following are its core characteristics and key parameters.
Product Features
Belonging to the Yaskawa Sigma II series, compatible with SGDH series drivers.
Rated power of 100W, suitable for small and medium load scenarios.
Rated speed of 3000 r/min, maximum speed of 5000 r/min, fast dynamic response.
Rated torque 0.318 N · m, peak torque 0.96 N · m.
The encoder type should be based on the physical nameplate markings, and there are two possibilities: absolute value or incremental type.
Protection level IP55 (excluding shaft extension), with dustproof and waterproof capabilities.
Some models come with 24V DC holding brakes, and it is necessary to confirm whether the actual product is equipped when selecting.
Adopting a straight shaft design with keyway for easy mechanical connection.
Weighing approximately 0.62kg (without brake), the structure is compact.
The insulation level is Class B.
Product Parameters
Brand: YASKAWA (Yaskawa Electric)
Model: SGMAH-01B1F41
Product Series: Sigma II
Rated power: 100W
Rated voltage: 100V AC
Summary
YASKAWA SGMAH-01B1F41 is a Sigma II series servo motor with a power of 100W and a voltage level of 100V. It needs to be paired with an SGDH driver for use
YASKAWA SGMAH-01B1F41 伺服电机 产品图片
