ACH550UH03A34 变频器 PDF资料
1.产 品 资 料 介 绍：
ACH550UH03A34 变频器
ACH550UH03A34 是ABB推出的一款低压交流变频器，专为风机、水泵等暖通空调应用设计，主打节能与智能控制。以下是其核心特点与关键参数。
产品特点
输出功率1.1kW，适配三相380-500V电源，防护等级IP21。
内置BACnet、Modbus协议，可接入楼宇自动化系统。
内置双PID控制器，无需外部设备即可实现闭环控制。
配备启动助手和故障诊断功能，调试维护方便。
内置谐波抑制功能，减少对电网的污染。
带有实时时钟，支持定时启停和事件记录。
标配操作面板，支持手/自动切换，便于现场操控。
结构紧凑，支持壁挂安装，节省空间。
针对风机水泵类负载预置应用宏，即选即用。
内置EMC滤波器和过载保护，运行稳定可靠。
产品参数输入电压：三相380-500V
输出功率：1.1kW
输出电流：3.3A
防护等级：IP21
工作温度：-15℃ ~ +40℃
总结
ACH550UH03A34 以节能高效、通讯灵活和操作简便为特点，是暖通空调系统中风机水泵控制的理想配套产品。
ACH550UH03A34 变频器 英文介绍
ACH550UH03A34 frequency converter
ACH550UH03A34 is a low-voltage AC frequency converter launched by ABB, designed specifically for HVAC applications such as fans and pumps, with a focus on energy conservation and intelligent control. The following are its core characteristics and key parameters.
Product Features
Output power of 1.1kW, compatible with three-phase 380-500V power supply, protection level IP21.
Built in BACnet and Modbus protocols, capable of connecting to building automation systems.
Built in dual PID controllers enable closed-loop control without the need for external devices.
Equipped with startup assistant and fault diagnosis function, easy to debug and maintain.
Built in harmonic suppression function to reduce pollution to the power grid.
Equipped with a real-time clock, supporting timed start stop and event recording.
Standard operating panel, supporting manual/automatic switching, easy to operate on site.
Compact structure, supports wall mounted installation, saves space.
Pre set application macros for fan and water pump loads, ready to use.
Built in EMC filter and overload protection, stable and reliable operation.
Product Parameters
Input voltage: three-phase 380-500V
Output power: 1.1kW
Output current: 3.3A
Protection level: IP21
Working temperature: -15 ℃~+40 ℃
Summary
ACH550UH03A34 is an ideal supporting product for fan and water pump control in HVAC systems, characterized by energy efficiency, flexible communication, and easy operation.
ACH550UH03A34 变频器 产品图片
