Orbotech 0398362B-T 相机组件 PDF资料
1.产 品 资 料 介 绍：
Orbotech 0398362B-T 相机组件
该相机组件为Orbotech AOI自动光学检测系统的核心成像部件，用于PCB、IC载板及平板显示等精密制造领域的在线质量检测。
产品特点
高分辨率图像传感器，捕捉精细电路图形与表面缺陷
多光谱照明设计，支持彩色成像，提升缺陷识别能力
内置自动对焦功能，保证不同厚度板面成像清晰
适配高速扫描检测系统，支持在线实时图像采集
低噪声电路设计，提高弱信号检测灵敏度
工业级封装结构，适应产线振动及温度变化环境
兼容Orbotech Discovery™、V-300™等检测平台
支持明场和暗场多种成像模式切换
配合多色LED闪光光源，增强不同材质对比度
标准通信接口，与系统控制单元协同完成检测
产品参数
型号：0398362B-T
类型：AOI相机组件/图像采集单元
品牌：Orbotech（奥宝科技）
适用领域：PCB裸板、IC载板、HDI板及软板检测
工作模式：自动对焦，配合闪频照明在线扫描成像
总之，Orbotech 0398362B-T 分辨率高、成像清晰、适配性强，是AOI检测系统的关键组件
Orbotech 0398362B-T camera module
This camera component is the core imaging component of Orbotech's AOI (Automatic Optical Inspection) system, used for online quality inspection in precision manufacturing fields such as PCB, IC carrier boards, and flat panel displays.
Product features
High-resolution image sensor, capturing fine circuit graphics and surface defects
Multispectral lighting design, supporting color imaging, enhancing defect identification capability
Built-in auto-focusing function, ensuring clear imaging of different thickness board surfaces
Compatible with high-speed scanning inspection system, supporting online real-time image acquisition
Low-noise circuit design, improving the sensitivity of weak signal detection
Industrial-grade packaging structure, adapting to the vibration and temperature changes in the production line
Compatible with inspection platforms such as Orbotech Discovery™ and V-300™
Supports switching between bright-field and dark-field imaging modes
Cooperates with multi-color LED flash light source to enhance contrast of different materials
Standard communication interface, working in coordination with the system control unit for inspection
Product Specifications
Model: 0398362B-T
Type: AOI camera component/Image acquisition unit
Brand: Orbotech (Orbotech Technology)
Application fields: PCB bare boards, IC carrier boards, HDI boards and flexible boards inspection
Working mode: Automatic focusing, combined with flash frequency lighting for online scanning imaging
In summary, Orbotech 0398362B-T has high resolution, clear imaging and strong adaptability, and is a key component of the AOI inspection system.
