HAMAMATSU L12745-01 闪光灯模块 PDF资料
1.产 品 资 料 介 绍：
HAMAMATSU L12745-01 是滨松公司推出的一款20瓦氙气闪光灯模块，集成了闪光灯、驱动电源和触发电路，适用于分析检测、半导体检查等场景。
产品特点
模块化一体设计，集成闪光灯与驱动电源，无需光轴校准即可直接安装使用。
体积小巧，外形尺寸为148毫米乘97毫米乘52毫米。
光输出稳定性高，典型值可达百分之零点五。
支持高重复频率工作，最高可达1000赫兹。
最大光源输入能量可达500毫焦耳。
主放电电压可在400至1000伏范围内调节。
内置触发输入接口，便于外部控制。
保证使用寿命可达1乘10的9次方次闪光。
无需强制风冷，自然冷却即可满足常规使用。
符合电磁兼容、安全及有害物质限制等多项国际标准。
产品参数
输入电压范围为21.6至26.4伏直流。
典型输入电流为1.5安培。
触发信号要求为矩形波5至10伏，脉宽不小于10微秒。
工作温度范围为0至40摄氏度。
储存温度范围为负40至90摄氏度。
结尾
HAMAMATSU L12745-01 氙气闪光灯模块以高稳定性、高重复频率和小型化设计，为光谱分析及半导体检测等应用提供了可靠的光源解决方案。
HAMAMATSU L12745-01 闪光灯模块 英文介绍
HAMAMATSU L12745-01 is a 20 watt xenon flash module launched by Hamamatsu Corporation, which integrates flash, driver power, and trigger circuit, suitable for analysis and detection, semiconductor inspection, and other scenarios.
Product Features
Modular integrated design, integrating flash and driver power, can be installed and used directly without optical axis calibration.
Compact in size, with dimensions of 148mm by 97mm by 52mm.
The light output stability is high, with a typical value of up to 0.5%.
Supports high repetition rate operation, up to 1000 Hz.
The maximum input energy of the light source can reach 500 millijoules.
The main discharge voltage can be adjusted within the range of 400 to 1000 volts.
Built in trigger input interface for easy external control.
Ensure a lifespan of up to 1 x 10 with a 9th power flash.
No need for forced air cooling, natural cooling is sufficient for regular use.
Compliant with multiple international standards such as electromagnetic compatibility, safety, and hazardous substance restrictions.
Product Parameters
The input voltage range is 21.6 to 26.4 volts DC.
The typical input current is 1.5 amperes.
The trigger signal requires a rectangular wave of 5 to 10 volts with a pulse width of no less than 10 microseconds.
The working temperature range is 0 to 40 degrees Celsius.
The storage temperature range is negative 40 to 90 degrees Celsius.
ending
The HAMAMATSU L12745-01 xenon flash module provides a reliable light source solution for applications such as spectral analysis and semiconductor detection due to its high stability, high repetition rate, and compact design.
HAMAMATSU L12745-01 闪光灯模块 产品图片
