SIEMENS 6SL3210-5BE32-2CV0 变频器 PDF资料
1.产 品 资 料 介 绍：
SIEMENS 6SL3210-5BE32-2CV0 变频器属于 SINAMICS V20 系列，是一款适用于三相交流电机调速的紧凑型变频驱动设备，具备高过载能力和集成多种接口的特点。
产品特点
额定功率22千瓦，支持150%过载运行60秒。
小过载模式下功率可达30千瓦，支持110%过载60秒。
输入电压范围为三相380～480VAC，适应工业标准电网。
内置集成C3级EMC滤波器，有效抑制电磁干扰。
配备6个数字量输入、2个数字量输出、2个模拟量输入及1个模拟量输出。
支持USS和MODBUS RTU现场总线通讯协议。
内置基本操作面板（BOP），便于现场调试与参数修改。
输出频率范围为0～599赫兹，满足宽范围调速需求。
额定输出电流为60安培，适用于大电流负载驱动。
防护等级为IP20，适合安装在控制柜内部使用。
产品参数
输入电压为三相380～480VAC，频率为47～63赫兹。
额定功率为22千瓦（重载）或30千瓦（轻载）。
额定电流为60安培。
工作温度范围为0至零上60摄氏度。
外形尺寸为宽度244毫米，高度265毫米，深度209毫米。
结尾
SIEMENS 6SL3210-5BE32-2CV0 变频器凭借其高过载能力、紧凑尺寸和丰富的通讯接口，为工业电机控制提供了可靠且灵活的驱动解决方案。
SIEMENS 6SL3210-5BE32-2CV0 变频器 英文介绍
The SIEMENS 6SL3210-5BE32-2CV0 frequency converter belongs to the SINAMICS V20 series and is a compact variable frequency drive device suitable for three-phase AC motor speed regulation. It has high overload capacity and integrates multiple interfaces.
Product Features
Rated power of 22 kW, supporting 150% overload operation for 60 seconds.
In small overload mode, the power can reach 30 kilowatts and support 110% overload for 60 seconds.
The input voltage range is three-phase 380-480VAC, suitable for industrial standard power grids.
Built in integrated C3 level EMC filter effectively suppresses electromagnetic interference.
Equipped with 6 digital inputs, 2 digital outputs, 2 analog inputs, and 1 analog output.
Supports USS and MODBUS RTU fieldbus communication protocols.
Built in Basic Operating Panel (BOP) for easy on-site debugging and parameter modification.
The output frequency range is 0-599 Hz, which meets the requirements of wide range speed regulation.
The rated output current is 60 amperes, suitable for driving high current loads.
The protection level is IP20, suitable for installation inside the control cabinet.
Product Parameters
The input voltage is three-phase 380-480VAC, with a frequency of 47-63 Hz.
The rated power is 22 kW (heavy load) or 30 kW (light load).
The rated current is 60 amperes.
The working temperature range is from 0 to 60 degrees Celsius above zero.
The external dimensions are a width of 244 millimeters, a height of 265 millimeters, and a depth of 209 millimeters.
ending
The SIEMENS 6SL3210-5BE32-2CV0 frequency converter provides a reliable and flexible drive solution for industrial motor control with its high overload capacity, compact size, and rich communication interfaces.
SIEMENS 6SL3210-5BE32-2CV0 变频器 产品图片
