ARTESYN TECHNOLOGIES IMP1-5Y1-3E-00 电源模块 PDF资料
1.产 品 资 料 介 绍：
ARTESYN TECHNOLOGIES IMP1-5Y1-3E-00 电源模块属于 iMP1 系列可配置 AC-DC 电源，是一款高灵活性、高功率密度的数字控制电源方案，适用于医疗、工业及通信设备。
产品特点
支持85～264VAC宽压输入，同时兼容120～300VDC输入。
最大输出功率可达1500W，满足高功率需求场景。
典型效率85%，节能且降低散热要求。
智能I²C/PMBus数字控制，可远程监控电压、电流及温度。
所有输出支持可编程电压、电流限值及输出时序控制。
内置主动式PFC（功率因数校正），功率因数高达0.99。
支持多路隔离输出，通过模块组合可实现最多21路输出。
满足医疗安规认证（EN60601-1），同时符合工业安全标准（EN60950）。
工作温度范围-40℃至+70℃（需降额），适应严苛环境。
可选配RS485、CANBus、MODBUS等通信协议接口。
产品参数
输入电压范围为85～264VAC，频率47～440Hz，同时兼容120～300VDC直流输入。
最大输出功率为1500瓦。
输入对输出的隔离电压为2000VAC。
工作环境温度范围为-40℃至零上70℃（高温区间需降额使用）。
外形尺寸为长度279.4毫米，宽度203.2毫米，高度63.5毫米。
结尾
ARTESYN TECHNOLOGIES IMP1-5Y1-3E-00 电源模块凭借其数字可编程能力、高功率密度和医疗级安全认证，为复杂多路输出系统提供了灵活可靠的电源解决方案。
ARTESYN TECHNOLOGIES IMP1-5Y1-3E-00 电源模块 英文介绍
The ARTESYN Technologies IMP1-5Y1-3E-00 power module belongs to the iMP1 series of configurable AC-DC power supplies. It is a highly flexible, high power density digital control power solution suitable for medical, industrial, and communication equipment.
Product Features
Supports 85-264VAC wide voltage input and is compatible with 120-300VDC input.
The maximum output power can reach 1500W, meeting high-power demand scenarios.
Typical efficiency of 85%, energy-saving and reducing heat dissipation requirements.
Intelligent I ² C/PMBus digital control, capable of remote monitoring of voltage, current, and temperature.
All outputs support programmable voltage, current limits, and output timing control.
Built in active PFC (power factor correction) with a power factor of up to 0.99.
Support multiple isolated outputs, up to 21 outputs can be achieved through module combination.
Meets medical safety certification (EN60601-1) and industrial safety standards (EN60950).
The working temperature range is -40 ℃ to+70 ℃ (with derating required), suitable for harsh environments.
Optional communication protocol interfaces such as RS485, CANBus, MODBUS, etc.
Product Parameters
The input voltage range is 85-264VAC, the frequency is 47-440Hz, and it is compatible with 120-300VDC DC input.
The maximum output power is 1500 watts.
The isolation voltage between input and output is 2000VAC.
The working environment temperature range is -40 ℃ to 70 ℃ above zero (high temperature range needs to be downgraded for use).
The external dimensions are 279.4 millimeters in length, 203.2 millimeters in width, and 63.5 millimeters in height.
ending
The ARTESYN Technologies IMP1-5Y1-3E-00 power module provides a flexible and reliable power solution for complex multi output systems with its digital programmability, high power density, and medical grade safety certification.
ARTESYN TECHNOLOGIES IMP1-5Y1-3E-00 电源模块 产品图片
