GENMARK  9900106611 系统控制器 PDF资料

1.产 品 资 料 介 绍：

GENMARK 9900106611 系统控制器是 Nidec Genmark 晶圆搬运及自动化系统的核心控制单元，负责执行精密运动控制与设备通信管理，广泛应用于半导体制造领域。以下是该型号的核心参数与特点。

产品参数

1. 产品定位：晶圆搬运机器人及 EFEM 系统控制器

2. 通信接口：支持 RS232（SECS-I）、Ethernet（HSMS）、TCP/IP 等

3. 软件支持：兼容 GB Toolbox 固件管理及控制器通信工具

4. 控制功能：支持多轴同步、S 曲线速度规划与连续路径控制

5. 配套产品：适用于 GPR 系列、GREX 系列等 Genmark 精密晶圆搬运机器人

产品特点

1. 专为半导体晶圆搬运设备设计，实现精确运动控制与定位

2. 支持多机器人结构控制，涵盖多自由度运动

3. 集成多项式样条与贝塞尔曲线的轨迹规划，确保运动平滑高效

4. 提供终端仿真器、诊断工具等丰富调试功能，便于现场维护

5. 支持 SECS/GEM 半导体行业通信标准，与工厂自动化系统无缝对接

6. 具备晶圆映射、自动对准及位置偏差补偿功能

7. 内置过载保护、位置跟踪误差检测等安全机制

8. 支持远程固件更新与参数在线编辑

9. 提供操纵杆或按键式机器人慢跑示教，操作便捷

10. 适配 300mm 晶圆处理，满足 Class 1 级洁净室环境要求

综上所述，GENMARK 9900106611 系统控制器是 Genmark 半导体自动化设备的核心控制组件，为晶圆搬运与精密定位提供了高效可靠的解决方案。

GENMARK  9900106611 系统控制器  英文介绍

The GENMARK 9900106611 system controller is the core control unit of Nidec Genmark wafer handling and automation system, responsible for executing precision motion control and equipment communication management, widely used in the semiconductor manufacturing field. The following are the core parameters and features of this model.

Product Parameters

Product positioning: Wafer handling robot and EFEM system controller

Communication interface: Supports RS232 (SECS-I), Ethernet (HSMS), TCP/IP, etc

Software support: Compatible with GB Toolbox firmware management and controller communication tools

Control function: Supports multi axis synchronization, S-curve speed planning, and continuous path control

Supporting products: Suitable for Genmark precision wafer handling robots such as GPR series, GREX series, etc

Product Features

Specially designed for semiconductor wafer handling equipment, achieving precise motion control and positioning

Support multi robot structure control, covering multi degree of freedom motion

Integrating polynomial spline and Bezier curve trajectory planning to ensure smooth and efficient motion

Provide rich debugging functions such as terminal simulators and diagnostic tools for easy on-site maintenance

Support SECS/GEM semiconductor industry communication standards and seamlessly integrate with factory automation systems

Equipped with wafer mapping, automatic alignment, and position deviation compensation functions

Built in overload protection, position tracking error detection and other safety mechanisms

Support remote firmware updates and online parameter editing

Provide joystick or button type robot jogging teaching, easy to operate

Compatible with 300mm wafer processing and meets Class 1 cleanroom environmental requirements

In summary, the GENMARK 9900106611 system controller is the core control component of Genmark semiconductor automation equipment, providing an efficient and reliable solution for wafer handling and precision positioning.

GENMARK  9900106611 系统控制器 产品图片
