HONEYWELL 900R12R-0300 12 槽机架冗余电源 PDF资料

1.产 品 资 料 介 绍：

Honeywell 900R12R-0300 是 ControlEdge HC900 系列的一款12槽I/O机架，专为支持冗余电源配置而设计，适用于需要高可用性的工业控制场合。以下是该型号的核心参数与特点。

产品参数

1. 槽位容量：12个I/O模块插槽，兼容HC900系列各类I/O模块

2. 电源支持：支持双冗余电源配置，机架预留双电源插槽位

3. 工作温度：宽温设计，支持-40°C至+70°C环境

4. 尺寸：137 mm（高）× 683.3 mm（宽）× 151.7 mm（深）

5. 重量：约5.25 kg

产品特点

1. 专为ControlEdge HC900平台设计，提供I/O模块的物理安装与背板连接

2. 支持双电源冗余供电，单路电源故障时可无扰切换

3. 背板集成双路独立供电母线，分别为逻辑电路和现场仪表提供电源

4. 支持模块热插拔，I/O模块可在系统带电状态下更换

5. 采用工业级金属外壳设计，具备良好的抗振动、抗电磁干扰能力

6. 支持DIN导轨安装或面板螺丝安装，适配标准19英寸机柜

7. 机架两端带扩展总线接口，可通过线缆串联扩展从机架

8. PCB板涂覆三防保形涂层，增强防潮、防尘、耐腐蚀能力

9. 每槽位独立机械锁扣，防止模块因振动松脱

10. 适用于石油化工、电力、水处理等对系统可靠性要求较高的关键过程控制场景

综上所述，Honeywell 900R12R-0300 是一款高密度、支持冗余供电的12槽I/O机架，为ControlEdge HC900系统提供了稳定可靠的模块安装与电源分配平台

HONEYWELL 900R12R-0300 12 槽机架冗余电源  英文介绍

Honeywell 900R12R-0300 is a 12 slot I/O rack from the ControlEdge HC900 series, designed to support redundant power configurations and suitable for industrial control applications that require high availability. The following are the core parameters and features of this model.

Product Parameters

Slot capacity: 12 I/O module slots, compatible with various types of I/O modules in the HC900 series

Power support: Supports dual redundant power configuration, with reserved dual power slots in the rack

Working temperature: wide temperature design, supporting environments from -40 ° C to+70 ° C

Dimensions: 137 mm (height) x 683.3 mm (width) x 151.7 mm (depth)

Weight: Approximately 5.25 kg

Product Features

Specially designed for the ControlEdge HC900 platform, providing physical installation of I/O modules and backplane connections

Supports dual power redundant power supply, and can switch without disturbance in case of single power failure

The backplane integrates dual independent power supply busbars, providing power for logic circuits and field instruments respectively

Support module hot plugging, I/O modules can be replaced while the system is powered on

Adopting industrial grade metal shell design, it has good anti vibration and anti electromagnetic interference capabilities

Supports DIN rail installation or panel screw installation, compatible with standard 19 inch cabinets

The rack has expansion bus interfaces at both ends, which can be connected in series through cables to expand from the rack

The PCB board is coated with a three proof conformal coating to enhance its moisture resistance, dust resistance, and corrosion resistance

Each slot has an independent mechanical lock to prevent the module from loosening due to vibration

Suitable for critical process control scenarios such as petrochemicals, electricity, water treatment, etc. that require high system reliability

In summary, Honeywell 900R12R-0300 is a high-density, redundant powered 12 slot I/O rack that provides a stable and reliable module installation and power distribution platform for the ControlEdge HC900 system

HONEYWELL 900R12R-0300 12 槽机架冗余电源 产品图片
