Bogen MCPCA3 控制卡模块 PDF资料
1.产 品 资 料 介 绍：
Bogen MCPCA3 是 Multicom 2000 行政通信系统中的核心处理器卡，负责系统的全部控制、音调生成和显示功能，适用于学校、机构及工业设施的内部通信与广播场景。
产品参数
类型：系统核心处理器卡。
安装位置：安装在机架式或壁挂式卡笼的第一个插槽中。
系统容量：单卡支持最多 240 个站点。
时钟：晶体控制实时时钟，带备用电池。
核心功能：系统控制、音调合成、DTMF 编码及显示驱动。
产品特点
包含全部系统内存，存储操作系统、配置及运行数据。
集成音频音调合成器，生成拨号音、回铃音等。
板载外部继电器驱动电路，用于控制外部设备。
配备 UART 接口，支持增强型管理电话功能。
支持现场软件升级，通过闪存加载程序更新。
支持 3 至 6 位房间号拨号方案，适应不同建筑规范。
支持直接拨打 911，并向管理电话发送报警及呼叫方 ID。
可通过 Bogen Commander 软件进行远程编程和诊断。
具备工厂复位功能，可通过菜单恢复默认设置。
控制 8 个管理分区、240 个寻呼分区及 8 个作息时间表。
结尾
综上所述，Bogen MCPCA3 处理器卡是 Multicom 2000 系统的核心控制组件，集成微处理器、存储和音调合成等关键功能，是实现高效行政通信与广播系统的关键模块。
Bogen MCPCA3 控制卡模块 英文介绍
Bogen MCPCA3 is the core processor card in the Multicom 2000 administrative communication system, responsible for all control, tone generation, and display functions of the system. It is suitable for internal communication and broadcasting scenarios in schools, institutions, and industrial facilities.
Product Parameters
Type: System Core Processor Card.
Installation position: Installed in the first slot of the rack mounted or wall mounted card cage.
System capacity: A single card can support up to 240 sites.
Clock: Crystal controlled real-time clock with backup battery.
Core functions: system control, tone synthesis, DTMF encoding, and display driver.
Product Features
Contains all system memory, storing operating system, configuration, and operational data.
Integrated audio tone synthesizer to generate dial tones, ringback tones, etc.
Onboard external relay drive circuit, used to control external devices.
Equipped with UART interface, supporting enhanced management phone functionality.
Support on-site software upgrades and update programs through flash loading.
Support 3 to 6-digit room number dialing schemes to adapt to different building codes.
Support direct dialing of 911 and sending the alarm and caller ID to the management phone.
Remote programming and diagnostics can be performed through Bogen Commander software.
Equipped with factory reset function, it can restore default settings through the menu.
Control 8 management partitions, 240 paging partitions, and 8 work schedules.
ending
In summary, the Bogen MCPCA3 processor card is the core control component of the Multicom 2000 system, integrating key functions such as microprocessor, storage, and tone synthesis. It is a key module for achieving efficient administrative communication and broadcasting systems.
Bogen MCPCA3 控制卡模块 产品图片
