Delta Tau 603625-102A UMAC-CPCI 数据系统 PCB PDF资料
1.产 品 资 料 介 绍：
Delta Tau 603625-102A 是 UMAC-CPCI 系统中的 Turbo CPU 主板，作为运动控制系统的核心处理器，负责多轴联动轨迹计算和实时伺服控制，适用于半导体设备、精密机床等需要高精度同步运动的场景。
产品参数
处理器：80 MHz DSP56303。
板载内存：128k × 24 SRAM（程序）+ 128k × 24 SRAM（数据）+ 1M × 8 Flash（固件）。
通信接口：RS-232/422 串口，可选 USB 或以太网。
总线形式：3U CompactPCI，通过背板与轴控卡、I/O 卡通信。
最大轴数：支持最多 32 轴扩展。
产品特点
为 UMAC-CPCI 系统核心 CPU 板，执行运动程序、伺服闭环和 PLC 任务。
采用 3U Eurocard 结构，插入 cPCI 机架背板。
通过背板与 Delta Tau 全系列轴控和 I/O 板卡高速通信。
板载 Flash 和电池备份 RAM，保存固件和用户程序。
支持多种上位机通信方式，便于调试和监控。
后面板引出所有现场信号，便于系统集成和维护。
可选配 CPCI 桥接子卡，扩展系统兼容性。
该 102 版本为早期型号，后续有 103/104/105 等升级版本。
广泛应用于半导体设备晶圆传输、精密扫描台等场景。
支持 PID+前馈伺服滤波、S 曲线加减速、电子齿轮、运动学变换等功能。
结尾
综上所述，Delta Tau 603625-102A 是 UMAC-CPCI 多轴运动控制系统的核心 CPU 主板，具备强大的运算能力和灵活的扩展性，适用于高精度运动控制场景
Delta Tau 603625-102A UMAC-CPCI 数据系统 PCB 英文介绍
Delta Tau 603625-102A is a Turbo CPU motherboard in UMAC-CPCI systems. As the core processor of motion control systems, it is responsible for multi axis linkage trajectory calculation and real-time servo control. It is suitable for scenarios such as semiconductor equipment and precision machine tools that require high-precision synchronous motion.
Product Parameters
Processor: 80 MHz DSP56303.
Onboard memory: 128k × 24 SRAM (program)+128k × 24 SRAM (data)+1M × 8 Flash (firmware).
Communication interface: RS-232/422 serial port, optional USB or Ethernet.
Bus form: 3U CompactPCI, communicates with the axis control card and I/O card through the backplane.
Maximum number of axes: Supports up to 32 axis expansion.
Product Features
Execute motion programs, servo closed-loop, and PLC tasks for the UMAC-CPCI system core CPU board.
Adopting a 3U Eurocard structure, inserted into the cPCI rack backplane.
High speed communication with Delta Tau's full range of axis control and I/O cards through the backplane.
Onboard Flash and battery backup RAM to store firmware and user programs.
Support multiple communication methods with the upper computer for easy debugging and monitoring.
The rear panel leads out all on-site signals for system integration and maintenance.
Optional CPCI bridging daughter card to expand system compatibility.
This 102 version is an early model, with subsequent upgraded versions such as 103/104/105.
Widely used in semiconductor equipment wafer transfer, precision scanning tables and other scenarios.
Support PID+feedforward servo filtering, S-curve acceleration and deceleration, electronic gears, kinematic transformation and other functions.
ending
In summary, Delta Tau 603625-102A is the core CPU motherboard of UMAC-CPCI multi axis motion control system, with strong computing power and flexible scalability, suitable for high-precision motion control scenarios
Delta Tau 603625-102A UMAC-CPCI 数据系统 PCB 产品图片
