PASABAN MTC-3052 输入 / 输出模块 PDF资料
1.产 品 资 料 介 绍：
Pasaban MTC-3052 是西班牙 MONTELEC 公司生产的一款高速数字 I/O 模块，用于连接传感器、编码器、电磁阀等现场设备，适用于造纸机械、包装设备等需要快速响应的工业场景。
产品参数
类型：高速数字 I/O 模块。
I/O 通道：16 路数字量输入，16 路晶体管输出。
输入电压：24V DC，带光电隔离。
输出参数：晶体管输出，24V DC/0.5A 每通道，带短路和过温保护。
高速性能：最高支持 10kHz 计数输入，响应时间最快 50μs。
产品特点
高速响应，适用于断纸检测、套准控制、高速切刀等场景。
部分输入通道可配置为高速计数器，接收编码器或接近开关信号。
输出可直接驱动小型电磁阀或固态继电器，无需外置放大电路。
每通道配有独立 LED 指示灯，状态一目了然。
采用光耦隔离设计，抗干扰能力强。
工作温度范围宽，适应工业现场环境。
支持 DIN 导轨安装，结构紧凑。
通过背板与 MTC 系列 PLC 通信，系统自动分配地址。
可作为已有 Pasaban 系统的备件或替换件使用。
常见于造纸机械、分切复卷机、包装机械等高速设备。
结尾
综上所述，Pasaban MTC-3052 高速 I/O 模块响应快、抗干扰能力强，适用于造纸和包装行业的高速设备控制场景。
PASABAN MTC-3052 输入 / 输出模块 英文介绍
Pasaban MTC-3052 is a high-speed digital I/O module produced by the Spanish company MONTELEC. It is used to connect field devices such as sensors, encoders, and solenoid valves, and is suitable for industrial scenarios such as paper machinery and packaging equipment that require rapid response.
Product Parameters
Type: High speed digital I/O module.
I/O channels: 16 digital inputs and 16 transistor outputs.
Input voltage: 24V DC, with photoelectric isolation.
Output parameters: transistor output, 24V DC/0.5A per channel, with short circuit and over temperature protection.
High speed performance: Supports up to 10kHz counting input, with a response time of up to 50 μ s.
Product Features
High speed response, suitable for scenarios such as paper breakage detection, register control, high-speed cutting blades, etc.
Some input channels can be configured as high-speed counters to receive encoder or proximity switch signals.
The output can directly drive small solenoid valves or solid-state relays without the need for external amplification circuits.
Each channel is equipped with independent LED indicator lights, making the status clear at a glance.
Adopting optocoupler isolation design, it has strong anti-interference ability.
Wide working temperature range, suitable for industrial site environment.
Supports DIN rail installation, compact structure.
By communicating with the MTC series PLC through the backplane, the system automatically assigns addresses.
Can be used as a spare or replacement part for existing Pasaban systems.
Commonly found in high-speed equipment such as paper making machinery, slitting and rewinding machines, and packaging machinery.
ending
In summary, the Pasaban MTC-3052 high-speed I/O module has fast response and strong anti-interference ability, making it suitable for high-speed equipment control scenarios in the paper and packaging industries.
PASABAN MTC-3052 输入 / 输出模块 产品图片
