PASABAN MTC-3044 PLC 机架 PDF资料
1.产 品 资 料 介 绍：
Pasaban MTC-3044 是西班牙 MONTELEC（MTC）公司生产的一款 PLC 机架，为 CPU 和各类 I/O 模块提供安装背板和电源支持，常见于印刷机、切纸机、纸张加工等工业设备中。
产品参数
槽位数量：4 个插槽，用于安装 Pasaban MTC-30xx 系列模块。
内置电源输入：100-240V AC，50/60Hz。
内置电源输出：+5V DC（5A）和 +24V DC（2A）。
结构尺寸：280mm（宽）× 160mm（高）× 150mm（深）。
工作环境：0°C 至 55°C，防护等级 IP20。
产品特点
4 槽紧凑设计，适用于中小规模控制应用。
集成电源供应单元，无需外置电源模块，简化柜内布线。
配备被动式背板，使用标准边缘连接器与模块对接。
兼容 Pasaban MTC-3xxx 系列数字量 I/O、模拟量 I/O 及 CPU 模块。
金属框架结构坚固耐用，支持 DIN 导轨或背板安装。
板载 LED 指示灯，可显示电源及故障状态。
电源具备过压、短路和过温保护功能。
采用自然对流散热，无风扇设计，适合粉尘环境。
常见于纸卷张力控制、分切复卷机、印刷机等设备。
符合 CE 和 RoHS 认证标准。
结尾
综上所述，Pasaban MTC-3044 PLC 机架集成了背板与电源，结构紧凑可靠，是构建 Pasaban MTC 系列小型控制系统的基础组件，特别适用于造纸和印刷行业的设备控制场景。
Pasaban MTC-3044 is a PLC rack produced by the Spanish company MONTELEC (MTC), which provides installation backboards and power support for CPUs and various I/O modules. It is commonly used in industrial equipment such as printing machines, paper cutters, and paper processing.
Product Parameters
Number of slots: 4 slots for installing Pasaban MTC-30xx series modules.
Built in power input: 100-240V AC, 50/60Hz.
Built in power output:+5V DC (5A) and+24V DC (2A).
Structural dimensions: 280mm (width) x 160mm (height) x 150mm (depth).
Working environment: 0 ° C to 55 ° C, protection level IP20.
Product Features
Compact design with 4 slots, suitable for small and medium-sized control applications.
Integrated power supply unit, no need for external power modules, simplifies cabinet wiring.
Equipped with a passive backplane, use standard edge connectors to interface with modules.
Compatible with Pasaban MTC-3xxx series digital I/O, analog I/O, and CPU modules.
The metal frame structure is sturdy and durable, supporting DIN rail or backplate installation.
Onboard LED indicator light, capable of displaying power and fault status.
The power supply has overvoltage, short circuit, and over temperature protection functions.
Adopting natural convection heat dissipation and fanless design, suitable for dusty environments.
Commonly used in equipment such as paper roll tension control, slitting and rewinding machines, printing machines, etc.
Compliant with CE and RoHS certification standards.
ending
In summary, the Pasaban MTC-3044 PLC rack integrates a backplane and power supply, with a compact and reliable structure. It is the basic component for building the Pasaban MTC series small control system and is particularly suitable for equipment control scenarios in the paper and printing industries.
