Alstom SKD11BF8003BCH 同步继电器 PDF资料
1.产 品 资 料 介 绍：
Alstom SKD11BF8003BCH 同步继电器产品特点
属于Alstom SKD系列检同步继电器，用于防止不合条件的电源并列运行。
主要用于联络线的自动重合闸序列中，配合自动重合闸继电器使用。
继电器触点串联在断路器合闸回路中，确保合闸前相位、电压和频率差均在预设范围内。
采用静态设计，低负担运行，精度高且稳定可靠。
具备抗瞬变和浪涌能力，可通过5kV冲击电压测试，适应电力系统严苛环境。
频率设定为50Hz，适用于标准工频电力系统。
电压锁定设置精度为±5%，确保电压差检测准确。
带计时器断开时动作时间约为200毫秒，响应快速。
额定电压下每路供电负担仅2.5VA，功耗低。
常用于发电机手动同步操作的安全检查，防止非同期合闸。
Alstom SKD11BF8003BCH 同步继电器参数
品牌Alstom，型号SKD11BF8003BCH。
继电器类型为静态检同步继电器。
供电电压110-220V AC/DC，适用电压范围宽。
额定电流5-30A，适用于工业场合。
工作频率50Hz，额定电压下负担2.5VA。
总结：Alstom SKD11BF8003BCH 是一款低负担、高可靠性的静态检同步继电器，适用于电力系统自动重合闸及发电机同步操作中的安全校验，确保断路器在安全条件下合闸。
Alstom SKD11BF8003BCH 同步继电器 英文介绍
Alstom SKD11BF8003BCH Synchronous Relay Product Features
Belonging to the Alstom SKD series synchronous relay, it is used to prevent non compliant power supply from running in parallel.
Mainly used in the automatic reclosing sequence of contact lines, in conjunction with automatic reclosing relays.
The relay contacts are connected in series in the circuit breaker closing circuit to ensure that the phase, voltage, and frequency differences are within the preset range before closing.
Adopting static design, low load operation, high precision and stable reliability.
Capable of withstanding transients and surges, able to pass 5kV impulse voltage testing and adapt to harsh environments in power systems.
The frequency is set to 50Hz, suitable for standard power frequency systems.
The voltage lock setting accuracy is ± 5%, ensuring accurate voltage difference detection.
The action time when the timer is disconnected is about 200 milliseconds, and the response is fast.
Under rated voltage, each power supply has a burden of only 2.5VA and low power consumption.
Commonly used for safety checks of manual synchronous operation of generators to prevent asynchronous closing.
Alstom SKD11BF8003BCH synchronous relay parameters
Brand Alstom, model SKD11BF8003BCH.
The relay type is a static synchronous relay.
The power supply voltage is 110-220V AC/DC, with a wide range of applicable voltages.
Rated current 5-30A, suitable for industrial applications.
The working frequency is 50Hz, and the load is 2.5VA under rated voltage.
Summary: Alstom SKD11BF8003BCH is a low burden, high reliability static synchronous relay suitable for safety verification in automatic reclosing and generator synchronization operations of power systems, ensuring that circuit breakers are closed under safe conditions.
Alstom SKD11BF8003BCH 同步继电器 产品图片
