Elmo TUB-15/230 伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
Elmo TUB-15/230 伺服驱动器产品特点
功率密度高，体积紧凑，节省安装空间。
支持230VAC交流供电，适配多种工业供电环境。
采用SimplIQ数字控制技术，性能稳定可靠。
支持CANopen和RS-232通信，系统集成方便。
支持位置、速度、电流三种控制模式，灵活满足不同应用需求。
适配直流有刷、无刷及直线电机，适用范围广。
支持增量式编码器与霍尔传感器反馈，兼容性强。
电流环采用矢量控制，转矩输出平稳高效。
支持宽温工作环境，适应多种工业现场条件。
配套Composer软件，可快速完成调试与参数整定。
Elmo TUB-15/230 伺服驱动器参数
连续输出功率约4.5kW，满足中等功率应用需求。
额定效率高达93%以上，节能效果显著。
峰值电流可达连续电流的2倍，满足短时过载需求。
尺寸为247×190×92mm，支持壁挂或DIN导轨安装。
需外接24VDC辅助电源供电，确保可靠运行。
总结：Elmo TUB-15/230 体积适中、性能可靠、控制灵活，适用于各类中功率工业伺服控制场景
Elmo TUB-15/230 servo drive product features
High power density, compact size, saving installation space.
Supports 230VAC AC power supply and is compatible with various industrial power supply environments.
Adopting SimplIQ digital control technology, the performance is stable and reliable.
Supports CANopen and RS-232 communication, making system integration convenient.
Supports three control modes: position, speed, and current, flexibly meeting different application requirements.
Suitable for DC brushed, brushless, and linear motors, with a wide range of applications.
Supports incremental encoders and Hall sensor feedback, with strong compatibility.
The current loop adopts vector control, and the torque output is stable and efficient.
Support a wide temperature working environment and adapt to various industrial site conditions.
Equipped with Composer software, it can quickly complete debugging and parameter tuning.
Elmo TUB-15/230 servo drive parameters
The continuous output power is about 4.5kW, meeting the requirements of medium power applications.
The rated efficiency is over 93%, and the energy-saving effect is significant.
The peak current can reach twice the continuous current, meeting the short-term overload demand.
The size is 247 × 190 × 92mm, supporting wall mounted or DIN rail installation.
An external 24VDC auxiliary power supply is required to ensure reliable operation.
Summary: Elmo TUB-15/230 is suitable for various medium power industrial servo control scenarios due to its moderate size, reliable performance, and flexible control
