SWIFT 0100-A355210 图像处理板组件 PDF资料
1.产 品 资 料 介 绍：
SWIFT 0100-A355210 图像处理板组件
SWIFT 0100-A355210 是一款图像处理板组件，属于 SWIFT 系列图像采集卡产品线，主要用于工业机器视觉领域，与 SWIFT 系列线扫描相机配套完成图像采集与数据传输任务。
SWIFT 0100-A355210 图像处理板组件 产品特点
采用 SOC 解决方案，集成度高，成本控制良好。
与 SWIFT 系列线扫描相机完全兼容，配套性好。
采用双 DMA 缓冲交替存储技术，数据传输稳定。
传输过程中 CPU 负载率接近 0%，释放主机资源。
支持实时在线机器视觉应用需求。
采用半高卡尺寸设计，适配嵌入式及小型化主机。
支持 32bit 33MHz PCI 总线接口。
平均突发数据传输率不低于 50M 字节/秒。
支持 Camera Link Base 1T8 模式线阵相机接口。
可编程标准通用异步串行接口，配置灵活。
可选配 I/O 扩展板，实现编码器信号接入。
支持相机外同步及外触发功能。
提供 Windows DLL 二次开发接口。
提供含源代码的 VC++ 演示例程，便于开发。
适用于工业视觉检测场景。
SWIFT 0100-A355210 图像处理板组件 产品参数
产品型号：SWIFT 0100-A355210。
产品类型：图像采集卡/图像处理板组件。
总线接口：32bit 33MHz PCI。
相机接口：Camera Link Base 1T8 模式。
数据传输率：不低于 50M 字节/秒。
SWIFT 0100-A355210 图像处理板组件以高集成度、低 CPU 负载和稳定的图像采集性能，成为工业机器视觉领域中 SWIFT 系列相机的配套选择。
SWIFT 0100-A355210 图像处理板组件 英文介绍
SWIFT 0100-A355210 Image Processing Board Component
SWIFT 0100-A355210 is an image processing board component belonging to the SWIFT series image acquisition card product line. It is mainly used in the field of industrial machine vision and is paired with SWIFT series line scanning cameras to complete image acquisition and data transmission tasks.
SWIFT 0100-A355210 Image Processing Board Component Product Features
Adopting SOC solution, high integration and good cost control.
Fully compatible with SWIFT series line scanning cameras, with good compatibility.
Adopting dual DMA buffer alternating storage technology ensures stable data transmission.
During the transmission process, the CPU load rate approaches 0%, freeing up host resources.
Support real-time online machine vision application requirements.
Adopting a semi high card size design, suitable for embedded and miniaturized hosts.
Supports 32-bit 33MHz PCI bus interface.
The average burst data transmission rate shall not be less than 50M bytes per second.
Supports Camera Link Base 1T8 mode linear array camera interface.
Programmable standard universal asynchronous serial interface, flexible configuration.
Optional I/O expansion board for encoder signal access.
Support camera external synchronization and external triggering functions.
Provide a secondary development interface for Windows DLL.
Provide VC++demonstration routines with source code for easy development.
Suitable for industrial visual inspection scenarios.
SWIFT 0100-A355210 Image Processing Board Component Product Parameters
Product model: SWIFT 0100-A355210.
Product type: Image acquisition card/image processing board component.
Bus interface: 32-bit 33MHz PCI.
Camera interface: Camera Link Base 1T8 mode.
Data transmission rate: not less than 50MB/s.
The SWIFT 0100-A355210 image processing board component has become a matching choice for SWIFT series cameras in the field of industrial machine vision due to its high integration, low CPU load, and stable image acquisition performance.
SWIFT 0100-A355210 图像处理板组件 产品图片
