MDD065A-N-040- N2M-095GB0伺服电机 PDF资料
1.产 品 资 料 介 绍：
MDD065A‑N‑040‑N2M‑095GB0 伺服电机简介
MDD065A‑N‑040‑N2M‑095GB0 是 Bosch Rexroth Indramat 旗下 MDD 系列同步伺服电机，属于工业级永磁同步伺服电机，适用于要求高精度、高动态响应的自动化机械和伺服控制系统。
核心特点
1. 永磁同步设计
永磁同步电机结构，输出稳定，效率高。
配合数字伺服驱动器，实现精确的位置、速度和扭矩控制。
2. 数字伺服反馈
内置多圈绝对编码器或数字伺服反馈（DSF），提供高精度位置与速度反馈。
支持闭环控制，实现高精度定位和快速动态响应。
3. 机械与结构
电机尺寸为 065 系列，安装方便。
输出轴为带密封光轴，无制动器。
中心直径约 95 mm，便于与联轴器或机械传动装置匹配。
4. 电气与性能
连续静止扭矩约 0.8 Nm，峰值扭矩约 2.3 Nm。
额定转速约 4000 rpm。
侧面接口用于编码器和电机接线连接。
设计适应工业环境，可自然散热使用。
典型应用
自动化生产线伺服定位控制
CNC 机床进给轴或主轴驱动
工业机器人关节与驱动单元
包装机械、印刷机及搬运系统等高精度应用
MDD065A-N-040- N2M-095GB0伺服电机 英文介绍
Introduction to MDD065A-N-040-N2M-095GB0 servo motor
MDD065A-N-040-N2M-095GB0 is an MDD series synchronous servo motor under Bosch Rexroth Indramat. It belongs to the industrial grade permanent magnet synchronous servo motor and is suitable for automation machinery and servo control systems that require high precision and high dynamic response.
Core Features
1. Permanent magnet synchronous design
Permanent magnet synchronous motor structure, stable output, high efficiency.
Cooperate with digital servo drives to achieve precise position, speed, and torque control.
2. Digital servo feedback
Built in multi turn absolute encoder or digital servo feedback (DSF), providing high-precision position and velocity feedback.
Support closed-loop control to achieve high-precision positioning and fast dynamic response.
3. Machinery and Structure
The motor size is 065 series, which is easy to install.
The output shaft is a sealed optical axis without a brake.
The center diameter is approximately 95 mm, making it easy to match with couplings or mechanical transmission devices.
4. Electrical and Performance
The continuous static torque is about 0.8 Nm, and the peak torque is about 2.3 Nm.
The rated speed is about 4000 rpm.
The side interface is used for connecting the encoder and motor wiring.
Designed to adapt to industrial environments and allow for natural heat dissipation.
Typical Applications
Servo positioning control of automated production line
CNC machine tool feed axis or spindle drive
Industrial robot joints and drive units
High precision applications such as packaging machinery, printing machines, and handling systems
MDD065A-N-040- N2M-095GB0伺服电机 产品展示
