AM247L-0001伺服电机 PDF资料
1.产 品 资 料 介 绍：
AM247L‑0001 伺服电机简介
AM247L‑0001 是 Beckhoff 生产的一款工业级 交流伺服电机，属于 AM 系列同步伺服电机。该电机常用于自动化系统、运动控制平台、CNC 设备和机器人等需要高精度定位与调速的场合。
主要性能特点
1. 高动态性能
三相交流永磁同步电机结构，响应快、控制精确。
配合专用伺服驱动器，可实现闭环控制，保证定位精度和速度控制。
2. 输出与工作参数
静止扭矩约 3 Nm。
额定转速约 3000 rpm。
静止电流约 2.3 A。
3. 反馈与控制
支持内置解析器或可选的单圈/多圈绝对编码器。
编码器提供精确位置和速度反馈，提升控制精度。
4. 电气与机械特性
额定电压约 230 V AC。
绝缘等级 F 级，耐热性能良好。
防护等级 IP65，适合工业现场防尘防水需求。
5. 结构与安装
电机重量约 3.9 kg。
标准 IEC 法兰设计，方便设备安装与更换。
AM247L-0001伺服电机 英文介绍
Introduction to AM247L-0001 servo motor
AM247L-0001 is an industrial grade AC servo motor produced by Beckhoff, belonging to the AM series synchronous servo motor. This motor is commonly used in automation systems, motion control platforms, CNC equipment, and robots that require high-precision positioning and speed regulation.
Main performance characteristics
1. High dynamic performance
The three-phase AC permanent magnet synchronous motor structure has fast response and precise control.
Combined with dedicated servo drives, closed-loop control can be achieved to ensure positioning accuracy and speed control.
2. Output and working parameters
The static torque is about 3 Nm.
The rated speed is about 3000 rpm.
The static current is about 2.3 amperes.
3. Feedback and Control
Support built-in parser or optional single/multi turn absolute encoder.
The encoder provides precise position and velocity feedback to improve control accuracy.
4. Electrical and mechanical characteristics
The rated voltage is approximately 230V AC.
Insulation grade F, good heat resistance.
Protection level IP65, suitable for dust and waterproof requirements in industrial sites.
5. Structure and Installation
The weight of the motor is approximately 3.9 kg.
Standard IEC flange design, convenient for equipment installation and replacement.
AM247L-0001伺服电机 产品展示
