1.产 品 资 料 介 绍：
B&R 5AP1120.0702‑C 控制面板简介
5AP1120.0702‑C 属于 B&R AP1000 系列操作面板，用于工业自动化系统的人机界面 (HMI)。该面板可用于显示设备状态、参数设置、报警提示以及操作输入，常与 B&R PLC 或控制单元配合使用。
主要规格与功能特性
显示屏尺寸：7 英寸 TFT 彩色显示屏
分辨率：800 × 480 像素 (16:10)
触摸方式：单点触控（电阻式）
供电：24 V DC
安装方式：面板嵌入安装
防护等级：前面板 IP65，背部 IP20
功能：用于 HMI 操作，包括状态显示、参数设定、报警提示及输入控制
适用环境：工业环境，可承受一般灰尘和液体飞溅
典型应用场景
工业设备主控制柜前端操作界面
自动化生产线监控与操作
包装、塑料成型、加工、装配机械设备的参数设定与状态监控
与 B&R PLC 系统集成，实现数据交换和操作控制
5AP1120.0702-C控制面板 英文介绍
Introduction to B&R 5AP1120.0702-C Control Panel
5AP1120.0702-C belongs to the B&R AP1000 series operation panel, which is used for the human-machine interface (HMI) of industrial automation systems. This panel can be used to display device status, parameter settings, alarm prompts, and operation inputs, and is often used in conjunction with B&R PLCs or control units.
Main specifications and functional characteristics
Display screen size: 7-inch TFT color display screen
Resolution: 800 × 480 pixels (16:10)
Touch mode: single touch (resistive)
Power supply: 24 V DC
Installation method: panel embedded installation
Protection level: front panel IP65, back IP20
Function: Used for HMI operation, including status display, parameter setting, alarm prompt, and input control
Applicable environment: Industrial environment, capable of withstanding general dust and liquid splashes
Typical application scenarios
Front end operation interface of industrial equipment main control cabinet
Automated production line monitoring and operation
Parameter setting and status monitoring of packaging, plastic molding, processing, and assembly machinery and equipment
Integrate with B&R PLC system to achieve data exchange and operational control
5AP1120.0702-C控制面板 产品展示
