G412-214A 伺服电机 PDF资料
1.产 品 资 料 介 绍：
MOOG G412-214A 伺服电机简介
G412-214A 属于 MOOG 高性能伺服电机系列，专为精密位置控制和高动态响应应用设计。该系列电机以高扭矩密度、低惯量和优异的调速性能闻名，广泛应用于航空航天、工业自动化、机器人和精密机械传动系统。
主要特点
高动态性能
低转子惯量设计，可快速响应位置、速度及转矩指令。高精度反馈
配备高分辨率编码器或光电旋转传感器，实现精准位置控制。稳定扭矩输出
优化电磁结构和散热设计，保证连续运行下的扭矩稳定性。坚固耐用
工业级外壳和轴承设计，可承受高负载、振动和冲击。兼容多种伺服驱动器
可与 MOOG 控制器或第三方高性能伺服驱动器配合使用。
典型技术参数（G412 系列参考）
具体参数需参考铭牌或 MOOG 产品手册，以下为常见参考值：
额定功率：约 1–3 kW（G412-214A 为中功率段）
额定转速：约 3000–5000 rpm
额定扭矩：约 4–10 N·m
最高转速：可达 6000 rpm 或更高
反馈装置：高分辨率编码器（增量或绝对型）
冷却方式：自然风冷或强制风冷（视配置）
安装方式：法兰安装
防护等级：通常 IP65（可选）
典型应用场景
工业机器人关节控制
航空航天测试台或伺服机构
自动化生产线的精密位置控制
卷绕、张力控制和高动态伺服轴
精密加工设备辅助轴
Introduction to MOOG G412-214A servo motor
G412-214A belongs to the MOOG high-performance servo motor series, designed specifically for precision position control and high dynamic response applications. This series of motors is renowned for its high torque density, low inertia, and excellent speed regulation performance, and is widely used in aerospace, industrial automation, robotics, and precision mechanical transmission systems.
Main Features
high dynamic performance
Low rotor inertia design, capable of quickly responding to position, speed, and torque commands.
High precision feedback
Equipped with high-resolution encoders or photoelectric rotation sensors to achieve precise position control.
Stable torque output
Optimize electromagnetic structure and heat dissipation design to ensure torque stability during continuous operation.
sturdy and durable
Industrial grade casing and bearing design, capable of withstanding high loads, vibrations, and impacts.
Compatible with multiple servo drives
Can be used in conjunction with MOOG controllers or third-party high-performance servo drives.
Typical technical parameters (G412 series reference)
Specific parameters should refer to the nameplate or MOOG product manual. The following are common reference values:
Rated power: approximately 1-3 kW (G412-214A is in the medium power range)
Rated speed: approximately 3000-5000 rpm
Rated torque: approximately 4-10 N · m
Maximum speed: up to 6000 rpm or higher
Feedback device: High resolution encoder (incremental or absolute type)
Cooling method: natural air cooling or forced air cooling (depending on configuration)
Installation method: flange installation
Protection level: Typically IP65 (optional)
Typical application scenarios
Joint control of industrial robots
Aerospace test bench or servo mechanism
Precise Position Control of Automated Production Lines
Winding, tension control, and high dynamic servo axis
Precision machining equipment auxiliary shaft
