1.产 品 资 料 介 绍：
Allen-Bradley 1756-IRT8I 热电偶模块简介
1756-IRT8I 属于 Allen-Bradley ControlLogix 系列 I/O 模块中的热电偶输入模块。该模块专为工业温度测量设计，可直接采集热电偶传感器信号，将温度数据传送至 ControlLogix 控制器进行监控和控制。
该型号模块以高精度测量、快速响应和多通道采集能力而受到自动化行业广泛应用。
主要特点
多通道输入
提供 8 个热电偶通道，可同时测量多点温度。兼容多种热电偶类型
支持常见热电偶类型，如 J、K、T、E、R、S、B 等。高精度测量
模块内置精确冷端补偿和温度线性化处理。快速采样
适用于对温度变化敏感的过程控制场景。与 ControlLogix 系统无缝集成
支持通过 1756 架构总线直接访问控制器，简化系统配置。诊断功能
可检测开路或短路热电偶，模块自带故障报警功能。
典型技术参数
输入通道：8 路热电偶输入
支持热电偶类型：J、K、T、E、R、S、B 等
采样速率：每通道约 10 ms（总采样周期约 80 ms）
分辨率：±0.1 °C（视测量范围而定）
冷端补偿：自动内部补偿
工作电压：由 ControlLogix 架构总线供电
安装方式：1756 架构机架插入式
工作温度：0…60°C（环境温度）
DFE24B/UOH11B通信接口模块 英文介绍
Introduction to Allen Bradley 1756-IRT8I Thermocouple Module
The 1756-IRT8I is a thermocouple input module in the Allen Bradley ControlLogix series of I/O modules. This module is designed specifically for industrial temperature measurement and can directly collect thermocouple sensor signals, transmitting temperature data to the ControlLogix controller for monitoring and control.
This model module is widely used in the automation industry for its high-precision measurement, fast response, and multi-channel acquisition capabilities.
Main Features
Multi channel input
Provide 8 thermocouple channels to measure multiple temperature points simultaneously.
Compatible with multiple types of thermocouples
Supports common thermocouple types such as J, K, T, E, R, S, B, etc.
high-precision measurement
The module is equipped with precise cold end compensation and temperature linearization processing.
Quick Sampling
Suitable for process control scenarios that are sensitive to temperature changes.
Seamless integration with ControlLogix system
Support direct access to the controller through the 1756 architecture bus, simplifying system configuration.
Diagnostic function
Can detect open or short circuit thermocouples, and the module comes with a fault alarm function.
Typical technical parameters
Input channel: 8 thermocouple inputs
Supports thermocouple types: J, K, T, E, R, S, B, etc
Sampling rate: approximately 10 ms per channel (total sampling period of approximately 80 ms)
Resolution: ± 0.1 ° C (depending on the measurement range)
Cold end compensation: automatic internal compensation
Working voltage: Powered by the ControlLogix architecture bus
Installation method: 1756 architecture rack insertion type
Working temperature: 0... 60 ° C (ambient temperature)
