MDFKABA090-22伺服电机 PDF资料
1.产 品 资 料 介 绍：
Lenze MDFKABA090-22 伺服电机简介
MDFKABA090-22 属于 Lenze MDFK 系列的交流伺服电机，该系列以稳定的扭矩输出、良好的动态性能以及高可靠性闻名，广泛用于自动化设备、机械传动系统和高精度运动控制领域。
型号中的 090 表示电机框号尺寸，属于中等功率段；22 通常对应线圈配置、额定速度及扭矩等级。
主要特点
输出稳定可靠：MDFK 系列提供连续、平滑的扭矩特性，适合需要高可靠性运行的设备。
良好的动态响应：启动快、加减速性能好，适用于频繁启停的自动化工况。
高精度反馈：兼容 Lenze 驱动器系统，反馈精度高，位置和速度控制表现稳定。
工业级结构设计：抗震、耐热性能出色，可在严苛工业环境中长期运行。
安装灵活：机体结构紧凑，同时支持多种标准安装接口。
典型技术参数范围（MDFK 090 系列常规参考）
实际参数因不同线圈代号略有差异，这里提供常见范围供资料使用：
额定功率：约 750W – 1.5kW
额定速度：一般 1500–3000 rpm
峰值速度：可达 4500 rpm 左右
额定扭矩：约 4 – 8 Nm
峰值扭矩：可达 10 – 20 Nm
编码器类型：增量或绝对值反馈（随配置变化）
冷却方式：自然冷却
防护等级：常见为 IP54/IP65
应用领域
包装机械
印刷与标签设备
自动化装配系统
传输与搬运设备
中小功率加工设备
电子制造与精密控制系统
Introduction to Lenze MDFKABA090-22 servo motor
MDFKABA090-22 belongs to the Lenze MDFK series of AC servo motors, which are renowned for their stable torque output, excellent dynamic performance, and high reliability. They are widely used in automation equipment, mechanical transmission systems, and high-precision motion control fields.
090 in the model indicates the motor frame size, which belongs to the medium power range; 22 usually corresponds to coil configuration, rated speed, and torque level.
Main Features
Stable and reliable output: The MDFK series provides continuous and smooth torque characteristics, suitable for equipment that requires high reliability operation.
Good dynamic response: fast start-up, good acceleration and deceleration performance, suitable for frequent start stop automation conditions.
High precision feedback: compatible with Lenze driver system, high feedback accuracy, stable position and speed control performance.
Industrial grade structural design: Excellent seismic and heat resistance, capable of long-term operation in harsh industrial environments.
Flexible installation: The body structure is compact and supports multiple standard installation interfaces.
Typical Technical Parameter Range (MDFK 090 Series Conventional Reference)
The actual parameters may vary slightly due to different coil codes. Here are common ranges provided for data use:
Rated power: approximately 750W-1.5kW
Rated speed: generally 1500-3000 rpm
Peak speed: up to around 4500 rpm
Rated torque: approximately 4-8 Nm
Peak torque: up to 10-20 Nm
Encoder type: Incremental or Absolute Feedback (varies with configuration)
Cooling method: natural cooling
Protection level: commonly IP54/IP65
Application field
packaging machinery
Printing and labeling equipment
Automated assembly system
Transmission and handling equipment
Small and medium power processing equipment
Electronic Manufacturing and Precision Control Systems
