2098-DSD-020X伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
AB 2098-DSD-020X 伺服驱动器简介
2098-DSD-020X 是 Allen-Bradley Ultra3000 系列中的一款数字式伺服驱动器（Ultra3000-DSD 类型）。该系列以高动态性能、丰富的控制模式和良好的系统兼容性著称，在自动化设备中广泛使用。
产品定位
这款驱动器主要用于控制中小容量的交流伺服电机，具备精准运动控制能力，适合要求高速响应、位置精度较高的场合。
主要特点
全数字伺服控制：响应快速，能够处理精密位置、速度与转矩控制。
多种控制方式：支持位置、速度、转矩、指令脉冲、模拟量输入等多模式。
优秀的动态表现：Ultra3000 系列具有高带宽伺服回路，适合快速启停和频繁动作的机械设备。
丰富的保护功能：具备过载、过流、过压、编码器异常、过热等完整保护机制。
通信能力强：支持工业控制系统常见接口，便于与 PLC、运动控制器集成。
参数设置灵活：可通过软件轻松配置，调试方便。
典型技术范围（Ultra3000-DSD 系列特性）
20 代表驱动容量等级，该等级通常用于 2.0kW 左右的伺服电机。
常规参数范围参考：
支持电机功率：约 1.5–2.0 kW
额定输出电流范围：与 020 等级相匹配的中等容量
输入电源：AC 输入
控制模式：位置/速度/力矩控制
反馈支持：增量编码器、伺服反馈接口
通讯：可支持 SERCOS、数字 I/O 指令等（依据具体版本）
适用领域
包装生产设备
自动装配机械
高速点位系统
电子制造设备
搬运、分拣及输送机械
CNC 辅助轴控制
Introduction to AB 2098-DSD-020X servo drive
2098-DSD-020X is a digital servo drive (Ultra3000-DSD type) in the Allen Bradley Ultra3000 series. This series is known for its high dynamic performance, rich control modes, and good system compatibility, and is widely used in automation equipment.
Product positioning
This driver is mainly used to control small and medium-sized AC servo motors, with precise motion control capabilities, suitable for situations that require high-speed response and high position accuracy.
Main Features
Full digital servo control: fast response, capable of handling precise position, speed, and torque control.
Multiple control modes: supporting multiple modes such as position, speed, torque, command pulse, analog input, etc.
Excellent dynamic performance: The Ultra3000 series features high bandwidth servo circuits, suitable for mechanical equipment with fast start stop and frequent movements.
Rich protection functions: equipped with complete protection mechanisms for overload, overcurrent, overvoltage, encoder abnormality, overheating, etc.
Strong communication capability: Supports common interfaces in industrial control systems, making it easy to integrate with PLCs and motion controllers.
Flexible parameter settings: can be easily configured through software, and debugging is convenient.
Typical technical scope (Ultra3000 DSD series features)
20 represents the drive capacity level, which is typically used for servo motors around 2.0kW.
Standard parameter range reference:
Supporting motor power: approximately 1.5-2.0 kW
Rated output current range: Medium capacity matched with 020 level
Input power supply: AC input
Control mode: position/speed/torque control
Feedback support: Incremental encoder, servo feedback interface
Communication: Supports SERCOS, digital I/O instructions, etc. (depending on the specific version)
Applicable fields
Packaging production equipment
Automatic assembly machinery
High speed point system
Electronic manufacturing equipment
Handling, sorting, and conveying machinery
CNC assisted axis control
