MSK060C-0300-N N-S1-UP0-NNNN 伺服电机 PDF资料
1.产 品 资 料 介 绍：
MSK060C-0300-N N-S1-UP0-NNNN 伺服电机简介
MSK060C-0300-N N-S1-UP0-NNNN 是博世力士乐（Bosch Rexroth）MSK 系列的一款高性能同步伺服电机。该系列以高精度、高功率密度和优异的动态响应著称，常用于需要高速定位与精密控制的先进自动化设备。
产品特性
高动态响应：转子惯量优化，适合快速启停、频繁反转等高动态应用。
高分辨率编码器系统：UP0 代表电机采用高精度绝对值编码器，便于进行精确位置与速度反馈。
紧凑结构：MSK060 尺寸段体积小、重量轻，安装方式灵活。
稳定输出：0300 规格代表其额定扭矩处于该系列中低段，适合中等负载应用。
优良散热：C 型机体具备良好的散热性能，提高持续输出能力。
典型技术参数范围
（MSK060 系列常见配置供参考，具体数值随版本略有差异）
额定扭矩：约 1.6–3.0 Nm
峰值扭矩：可达 4–8 Nm
额定速度：一般 3000 rpm 左右
峰值速度：可至 4500–6000 rpm
反馈方式：高分辨率绝对值编码器
冷却方式：自然风冷
绝缘等级：F 级
典型应用
精密传动机构
自动化装配线
电子半导体设备
包装机械
CNC 中小轴伺服系统
高速点位系统与搬运设备
MSK060C-0300-N N-S1-UP0-NNNN 伺服电机 英文介绍
Introduction to MSK060C-0300-N N-S1-UP0-NNNN servo motor
MSK060C-0300-N N-S1-UP0-NNNN is a high-performance synchronous servo motor from Bosch Rexroth's MSK series. This series is known for its high precision, high power density, and excellent dynamic response, and is commonly used in advanced automation equipment that requires high-speed positioning and precise control.
Product Features
High dynamic response: optimized rotor inertia, suitable for high dynamic applications such as fast start stop and frequent reversal.
High resolution encoder system: UP0 represents the motor using a high-precision absolute value encoder, which facilitates precise position and velocity feedback.
Compact structure: MSK060 size segment has small volume, light weight, and flexible installation method.
Stable output: The 0300 specification represents its rated torque in the mid to low range of the series, suitable for medium load applications.
Excellent heat dissipation: The C-type body has good heat dissipation performance, improving continuous output capability.
Typical technical parameter range
(MSK060 series common configurations for reference, specific values may vary slightly depending on the version)
Rated torque: approximately 1.6-3.0 Nm
Peak torque: up to 4-8 Nm
Rated speed: generally around 3000 rpm
Peak speed: up to 4500-6000 rpm
Feedback method: High resolution absolute value encoder
Cooling method: natural air cooling
Insulation level: F level
Typical Applications
Precision transmission mechanism
Automated assembly line
Electronic semiconductor equipment
packaging machinery
CNC small axis servo system
High speed point system and handling equipment
MSK060C-0300-N N-S1-UP0-NNNN 伺服电机 产品展示
