VT-HNC100-1-22/W-08-0-0数字轴控制器 PDF资料
1.产 品 资 料 介 绍：
Rexroth VT-HNC100-1-22/W-08-0-0 数字轴控制器简介
VT-HNC100 系列是 Bosch Rexroth 专为液压轴（Hydraulic Axis）与复杂运动控制开发的数字控制器。该模块可将伺服液压系统提升到数控级别的精度，通过闭环控制实现位移、速度和压力的高动态调节。
型号 VT-HNC100-1-22/W-08-0-0 为该系列常见配置，适用于中高速响应的液压执行机构、压力控制站及多轴同步系统。
主要功能与特点
1. 内置多种闭环控制模式
位置控制（Position）
速度控制（Velocity）
压力/力控制（Pressure/Force）
复合控制（如位置+压力切换）
适合高精度液压缸位置、压力、张力等工业场景。
2. 独立单轴控制能力
本型号为 单轴数字控制器（Single Axis Controller），具备独立的控制逻辑，可直接驱动液压伺服阀或比例阀。
3. 支持多种输入反馈信号
可接入：
位置反馈（SSI、增量编码器、LVDT 等）
压力传感器
模拟量输入（位移、电流、压力等）
反馈种类丰富，可适配多种液压执行单元。
4. 高速度控制循环（高速闭环）
内置高速 CPU，可实现快速控制周期，有利于提高液压轴的：
响应速度
控制精度
稳定性
特别适合高速冲压、压机平台、伺服液压执行机构。
VT-HNC100-1-22/W-08-0-0数字轴控制器 英文介绍
Introduction to Rexroth VT-HNC100-1-22/W-08-0-0 Digital Axis Controller
The VT-HNC100 series is a digital controller developed by Bosch Rexroth specifically for hydraulic axes and complex motion control. This module can elevate the precision of the servo hydraulic system to the level of numerical control, and achieve high dynamic adjustment of displacement, speed, and pressure through closed-loop control.
The model VT-HNC100-1-22/W-08-0-0 is a common configuration in this series, suitable for hydraulic actuators, pressure control stations, and multi axis synchronization systems with medium to high speed response.
Main functions and features
1. Built in multiple closed-loop control modes
Position control
Velocity control
Pressure/Force Control
Composite control (such as position+pressure switching)
Suitable for industrial scenarios such as high-precision hydraulic cylinder position, pressure, tension, etc.
2. Independent single axis control capability
This model is a Single Axis Controller with independent control logic, which can directly drive hydraulic servo valves or proportional valves.
3. Support multiple input feedback signals
Can be accessed:
Position feedback (SSI, incremental encoder, LVDT, etc.)
pressure sensor
Analog inputs (displacement, current, pressure, etc.)
The feedback types are diverse and can be adapted to various hydraulic execution units.
4. High speed control loop (high-speed closed-loop)
Equipped with a high-speed CPU, it can achieve fast control cycles, which is beneficial for improving the performance of hydraulic shafts
response speed
control accuracy
stability
Especially suitable for high-speed stamping, press platforms, and servo hydraulic actuators.
VT-HNC100-1-22/W-08-0-0数字轴控制器 产品展示
