MDD071B-N-030- N2S-095GA0伺服电机 PDF资料
1.产 品 资 料 介 绍：
MDD071B-N-030-N2S-095GA0 伺服电机简介
该型号属于 Bosch Rexroth/Indramat 的 MDD 系列高速交流伺服电机，特点是转速高、惯量低、响应快，适用于对加速度与重复定位精度要求较高的设备，如数控机床、包装机械、电子制造设备、自动化运动轴等。
结构与性能特点
稀土永磁同步伺服结构
在高速下仍能保持稳定扭矩输出，电机效率高。低惯量设计（Low Inertia）
适合快速反向、短周期节拍、频繁启停的运动构架。高分辨率反馈系统
“N2S” 表示内置数字式孪生编码器（Digital Servo Feedback），可用在 Indramat 驱动器系统中实现高精度闭环控制。高可靠性机械构造
轴承寿命长，外壳散热性能优良，适合长时间连续运行。标准法兰安装
便于机械集成，适合设备改造和直替应用。
型号代码解析
MDD071B：机座号 071，B 为机身长度等级
N-030：指定绕组代码，表示额定转速约 3000 rpm 等级
N2S：数字式伺服反馈编码器（高分辨率）
095GA0：指定轴伸、安装法兰尺寸 95 mm、轴承/密封形式及电缆出口方向等机械细节
典型技术范围（基于 MDD071 系列）
具体数值会因绕组代码而略有不同，下面为此尺寸等级常见范围，与你的型号接近：
额定扭矩：约 1.5～4 N·m
峰值扭矩：可达 3 倍额定
额定转速：约 3000 rpm
最高转速：通常可达 4500–6000 rpm
绝缘等级：F 级
防护等级：一般为 IP65（轴伸区常为 IP54）
冷却方式：表面散热，自然风冷
MDD071B-N-030- N2S-095GA0伺服电机 英文介绍
Introduction to MDD071B-N-030-N2S-095GA0 servo motor
This model belongs to Bosch Rexroth/Andramat's MDD series high-speed AC servo motor, which is characterized by high speed, low inertia, and fast response. It is suitable for equipment with high requirements for acceleration and repeat positioning accuracy, such as CNC machine tools, packaging machinery, electronic manufacturing equipment, automated moving shafts, etc.
Structure and Performance Characteristics
Rare earth permanent magnet synchronous servo structure
It can maintain stable torque output at high speeds and has high motor efficiency.
Low Inertia Design
Suitable for fast reverse, short cycle rhythm, and frequent start stop motion structures.
High resolution feedback system
N2S "refers to a built-in digital twin encoder (Digital Servo Feedback) that can be used in Indramat drive systems to achieve high-precision closed-loop control.
High reliability mechanical construction
Long bearing life, excellent heat dissipation performance of the shell, suitable for long-term continuous operation.
Standard flange installation
Easy for mechanical integration, suitable for equipment modification and direct replacement applications.
Model code analysis
MDD071B: Machine base number 071, B is the length grade of the fuselage
N-030: Specify winding code, indicating rated speed of approximately 3000 rpm level
N2S: Digital servo feedback encoder (high-resolution)
095GA0: Specify mechanical details such as shaft extension, installation flange size of 95mm, bearing/sealing form, and cable outlet direction
Typical technical scope (based on MDD071 series)
The specific values may vary slightly depending on the winding code. Below is a common range for this size grade, which is similar to your model:
Rated torque: approximately 1.5-4 N · m
Peak torque: up to 3 times rated
Rated speed: approximately 3000 rpm
Maximum speed: usually up to 4500-6000 rpm
Insulation level: F level
Protection level: generally IP65 (shaft extension area is often IP54)
Cooling method: surface heat dissipation, natural air cooling
MDD071B-N-030- N2S-095GA0伺服电机 产品展示
