1024G-90G-NG-J编码器 PDF资料
1.产 品 资 料 介 绍：
1024G-90G-NG-J 编码器简介
1024G-90G-NG-J 是一款用于工业自动化和运动控制设备的高分辨率旋转编码器，常见于定位系统、伺服机构、速度反馈回路以及精密测控平台。其名称中的 “1024G” 通常代表编码器具有 1024 脉冲/转（PPR） 的解析度，可提供较高的角度检测精度。
该型号以结构紧凑、输出稳定、抗干扰能力强而著称，适用于各种机械设备的高频运行和持续反馈。
主要性能特点
● 1024PPR 高分辨率
能够将每一转分为 1024 个脉冲，使位置变化与速度反馈更加精准，适用于伺服、定位与速度控制系统。
● 90° 机械结构适配性强
通常配备标准化轴径与安装尺寸，方便与电机、旋转平台或减速机配合安装。
● 输出信号稳定
多采用差分或集电极开路输出，适合长距离传输，抗干扰能力佳。
● 工业级耐用性
外壳坚固，多具备防尘、防震、防油污的特点，可在连续运行环境下保持稳定反馈。
● 高速响应性能
能够在高速旋转场景中保持脉冲清晰，不会出现误码或丢脉冲。
典型应用场合
伺服电机和步进电机的速度/位置反馈
自动化机械的定位控制系统
印刷、包装、纺织等需要高精度同步的设备
机器人关节或滑台行程监测
数控机床、加工中心的轴向位置检测
输送线和运动平台的速度监控
1024G-90G-NG-J编码器 英文介绍
Introduction to 1024G-90G-NG-J Encoder
1024G-90G-NG-J is a high-resolution rotary encoder used in industrial automation and motion control equipment, commonly found in positioning systems, servo mechanisms, speed feedback loops, and precision measurement and control platforms. The "1024G" in its name usually represents an encoder with a resolution of 1024 pulses per revolution (PPR), which can provide high angle detection accuracy.
This model is known for its compact structure, stable output, and strong anti-interference ability, and is suitable for high-frequency operation and continuous feedback of various mechanical equipment.
Main performance characteristics
● 1024PPR high resolution
It can divide each revolution into 1024 pulses, making position changes and speed feedback more accurate, suitable for servo, positioning, and speed control systems.
Strong adaptability to 90 ° mechanical structure
Usually equipped with standardized shaft diameter and installation dimensions, it is convenient to install in conjunction with motors, rotating platforms, or reducers.
● Stable output signal
It often uses differential or open collector output, suitable for long-distance transmission, and has good anti-interference ability.
● Industrial grade durability
The shell is sturdy and has the characteristics of dust prevention, shock resistance, and oil pollution prevention, which can maintain stable feedback in continuous operating environments.
● High speed response performance
It can maintain clear pulses in high-speed rotating scenes without errors or missing pulses.
Typical application scenarios
Speed/position feedback of servo motors and stepper motors
Positioning control system for automated machinery
Printing, packaging, textile and other equipment that require high-precision synchronization
Robot joint or slide table travel monitoring
Axial position detection of CNC machine tools and machining centers
Speed monitoring of conveyor lines and motion platforms
1024G-90G-NG-J编码器 产品展示
