AEG MODICON AS-B875-102热电偶输入模块 PDF资料
1.产 品 资 料 介 绍：
AS-B875-102 热电偶输入模块简介
AS-B875-102 是 Modicon 800 系列中的一款多功能模拟输入模块，专门用于采集工业现场的温度信号。它支持多种热电偶类型，并能将微弱的温度电压信号转换为 PLC 可处理的数字量，用于工艺控制、温度监测等场景。
主要功能特点
◆ 多类型热电偶输入
模块可兼容常见的工业热电偶，例如：
J 型、K 型、T 型、E 型、R 型、S 型等。
满足从低温到高温的广泛测量需求。
◆ 多通道采集能力
通常为多路模拟输入，可同时接入多个测点，适合多点温度监控或分布式热力检测场合。
◆ 高精度 A/D 转换
内置高分辨率转换电路，有效提升温度采集的稳定性与灵敏度，适用于对精度有要求的过程控制系统。
◆ 通道隔离设计
通道之间具备电气隔离，有助于减少干扰、提高整体测量质量，避免信号串扰。
◆ 背板供电与模块化结构
安装在 Modicon 800 系列标准背板上，通过统一总线供电与通信，方便扩展与维护。
典型应用
多温区加热设备的温度采集
工业炉、烘箱、热处理设备
过程控制系统的环境温度监测
需要同时管理多路温度信号的工业现场
老旧 AEG / Modicon 系统的温度输入扩展
AEG MODICON AS-B875-102热电偶输入模块 英文介绍
Introduction to AS-B875-102 Thermocouple Input Module
AS-B875-102 is a multifunctional analog input module in the Modicon 800 series, specifically designed for collecting temperature signals from industrial sites. It supports multiple types of thermocouples and can convert weak temperature and voltage signals into digital quantities that can be processed by PLC for use in process control, temperature monitoring, and other scenarios.
Main functional features
◆ Multiple types of thermocouple inputs
The module is compatible with common industrial thermocouples, such as:
J-type, K-type, T-type, E-type, R-type, S-type, etc.
Meet a wide range of measurement needs from low to high temperatures.
◆ Multi channel acquisition capability
It is usually a multi-channel analog input that can be connected to multiple measuring points simultaneously, suitable for multi-point temperature monitoring or distributed thermal detection scenarios.
High precision A/D conversion
Built in high-resolution conversion circuit effectively improves the stability and sensitivity of temperature acquisition, suitable for process control systems with precision requirements.
◆ Channel isolation design
Electrical isolation between channels helps reduce interference, improve overall measurement quality, and avoid signal crosstalk.
Backboard power supply and modular structure
Installed on the Modicon 800 series standard backplane, it is powered and communicated through a unified bus for easy expansion and maintenance.
Typical Applications
Temperature acquisition of multi zone heating equipment
Industrial furnaces, ovens, and heat treatment equipment
Environmental temperature monitoring of process control system
Industrial sites that require simultaneous management of multiple temperature signals
Expansion of Temperature Input for Old AEG/Modicon Systems
AEG MODICON AS-B875-102热电偶输入模块 产品展示
