AEG MODICON AS-HDTA-200主副架插槽 PDF资料

1.产 品 资 料 介 绍：

AEG MODICON AS-HDTA-200 主副架插槽

AS-HDTA-200 是 Modicon 系列系统中用于主、副控制架或扩展机架的插槽模块，主要功能是为 CPU、I/O 模块及通信模块提供标准化安装接口，并确保主副架之间或扩展机架的数据和电源连接稳定可靠。它在系统中起到机械支撑、信号桥接和背板通信协调的作用，是大型自动化控制系统的重要硬件组成部分。

主要功能

1. 模块安装与固定
   提供标准化插槽，便于各类模块安全、稳固地安装在机架中。

2. 主副架通信桥接
   确保主控架与副控架之间的数据同步和通信稳定，实现双机冗余或分布式控制。

3. 扩展支持
   可用于连接远端或扩展机架，为系统增加 I/O 点数或功能模块提供接口。

4. 电源分配与信号传输
   通过背板完成电源和通信信号分配，为各模块提供统一接口。

结构与特性

• 工业级设计，抗震、抗干扰能力强，适合连续运行环境。

• 插槽布局清晰，支持多种 Modicon CPU、I/O、通信模块兼容安装。

• 背板通信线路经过优化，保证数据传输的实时性与可靠性。

• 机架间连接灵活，便于系统扩展或模块替换。

• 可承载主控架和副控架的双机配置，实现冗余或备份功能。

典型应用场景

• 大型工厂自动化控制柜内的主、副控制架安装

• 分布式控制系统的机架扩展与冗余配置

• 化工、电力、冶金、钢铁等行业的连续生产控制站

• 系统扩容或老旧 Modicon 平台维保项目

• 需要模块化安装与双机冗余的控制场合

AEG MODICON AS-HDTA-200主副架插槽 英文介绍

AEG MODICON AS-HDTA-200 main and secondary rack slots

AS-HDTA-200 is a slot module used in the Modicon series system for main and auxiliary control racks or expansion racks. Its main function is to provide standardized installation interfaces for CPU, I/O modules, and communication modules, and ensure stable and reliable data and power connections between main and auxiliary racks or expansion racks. It plays a role in mechanical support, signal bridging, and backplane communication coordination in the system, and is an important hardware component of large-scale automation control systems.

Main functions

Module installation and fixation

Provide standardized slots for safe and secure installation of various modules in the rack.

Main and auxiliary frame communication bridge

Ensure data synchronization and stable communication between the main control rack and the auxiliary control rack, and achieve dual machine redundancy or distributed control.

Extended support

Can be used to connect to remote or expansion racks, providing interfaces for increasing I/O points or functional modules in the system.

Power distribution and signal transmission

Complete power and communication signal distribution through the backplane, providing a unified interface for each module.

Structure and Characteristics

Industrial grade design, strong seismic and anti-interference capabilities, suitable for continuous operation environment.

The slot layout is clear and supports compatible installation of multiple Modicon CPUs, I/O, and communication modules.

The backplane communication line has been optimized to ensure real-time and reliable data transmission.

Flexible connections between racks facilitate system expansion or module replacement.

Can support dual machine configuration of main control rack and auxiliary control rack, achieving redundancy or backup function.

Typical application scenarios

Installation of main and auxiliary control frames in the automation control cabinet of large factories

Rack Expansion and Redundant Configuration of Distributed Control Systems

Continuous production control stations for industries such as chemical, power, metallurgy, and steel

System expansion or maintenance project for outdated Modicon platform

Control scenarios that require modular installation and dual machine redundancy
