AEG MODICON RTC-8700可编程式逻辑控制器 PDF资料
1.产 品 资 料 介 绍：
AEG MODICON RTC-8700 可编程式逻辑控制器
RTC-8700 是 AEG/Modicon 体系中较早期、但在工业现场长期使用的可编程式逻辑控制器。它作为系统的主控制单元，负责逻辑扫描、数据处理、程序执行和现场设备协调，是整套控制架构的核心部分。该型号以结构稳固、运行可靠、适应性强而闻名，常见于连续生产型行业。
核心功能
程序逻辑执行
负责运行用户编写的控制流程，包括顺序控制、逻辑判断、计时计数和状态管理。数据采集与处理
持续与输入模块交换数据，实时记录设备状态并执行逻辑运算。动作输出协调
将处理后的结果同步至输出模块，使执行机构按节奏运行。通信与扩展管理
支持与扩展机架、远程 I/O、通信模块协同工作，构建完整控制网络。
结构与性能特性
采用工业级设计，强调长期运行的稳定性与环境适应能力。
扫描周期稳定，可处理多点数据与复杂逻辑。
内置存储区用于保存逻辑程序及关键参数。
与传统 Modicon I/O 模块体系兼容，便于扩展点数或替换旧设备。
能够在高干扰、电磁复杂的环境中持续运行。
典型应用行业
化工生产线
电力设备控制
建材、冶金、钢铁加工
水处理、环保系统
机械制造与连续自动化工段
仍在运行的老式工厂控制系统升级维护项目
使用优势
运行稳定，适合长周期、24 小时连续生产的环境
模块化结构，维护与替换方便
对老旧系统兼容性高，适用于存量工厂的延寿工程
控制逻辑清晰，可支持多样化的自动化场景
故障率低，维修人员易于诊断与处理
AEG MODICON RTC-8700可编程式逻辑控制器 英文介绍
AEG MODICON RTC-8700 Programmable Logic Controller
RTC-8700 is an early programmable logic controller in the AEG/Modicon system, but has been used in industrial settings for a long time. As the main control unit of the system, it is responsible for logic scanning, data processing, program execution, and on-site equipment coordination, and is the core part of the entire control architecture. This model is known for its stable structure, reliable operation, and strong adaptability, and is commonly used in continuous production industries.
core functionality
Program logic execution
Responsible for running user written control processes, including sequential control, logical judgment, timing and counting, and status management.
data acquisition and processing
Continuously exchange data with input modules, record device status in real-time, and perform logical operations.
Action output coordination
Synchronize the processed results to the output module to enable the execution mechanism to run rhythmically.
Communication and Expansion Management
Support collaborative work with expansion racks, remote I/O, and communication modules to build a complete control network.
Structure and Performance Characteristics
Adopting industrial grade design, emphasizing long-term stability and environmental adaptability.
The scanning cycle is stable and can handle multi-point data and complex logic.
The built-in storage area is used to store logical programs and key parameters.
Compatible with the traditional Modicon I/O module system, making it easy to expand points or replace old devices.
Capable of continuous operation in high interference and complex electromagnetic environments.
Typical application industries
Chemical production line
Power equipment control
Building materials, metallurgy, and steel processing
Water treatment and environmental protection system
Mechanical Manufacturing and Continuous Automation Section
Upgrade and maintenance project for old factory control system still in operation
Advantages of use
Stable operation, suitable for environments with long cycles and 24-hour continuous production
Modular structure, easy to maintain and replace
High compatibility with old systems, suitable for life extension projects in existing factories
Clear control logic, capable of supporting diverse automation scenarios
Low failure rate, easy for maintenance personnel to diagnose and handle
