1.产 品 资 料 介 绍：
AEG Modicon 6051-042.23964 — 模块概述
这款 6051-042.23964 模块属于 AEG Modicon 系列的过程量采集与输出单元，专门用于对现场的模拟信号进行高精度读取与稳定输出。六通道的结构设计使其能够在有限空间内同时管理多路关键过程数据，非常适合中小型过程控制站点。
功能定位
它的主要作用是：
读取：采集现场传感器输出的电流或电压信号
转换：将模拟量转换为控制器可处理的数字量
输出：根据控制器指令生成精确的模拟控制信号，驱动执行设备
属于典型的 AI/AO 组合式模拟量模块。
通道配置特点
1. 六通道设计
输入与输出资源按需分配，可实现多路监测与多路控制并行运行。
模块支持多个输入类型，例如 4–20 mA、0–10 V（具体取决于系统配置）。
2. 信号处理精度稳定
内部具备模数转换与滤波机制，可有效减轻噪声对采样精度的影响，保证采集数据的可靠性。
3. 输出能力可驱动现场设备
输出通道能生成稳定的模拟控制信号，常用于调节阀门、变频器、执行机构的调节命令。
电气与保护设计
每个通道通常具备隔离与过压保护，减少互相干扰
具备错误检测能力，能识别开路、短路等典型信号异常
运行过程温漂小，适合长期连续运行的控制系统
AEG MODICON 6051-042.23964 6模拟输入输出模块 英文介绍
AEG Modicon 6051-04.23964- Module Overview
This 6051-042.23964 module belongs to the AEG Modicon series of process quantity acquisition and output units, specifically designed for high-precision reading and stable output of analog signals on site. The six channel structural design enables it to manage multiple critical process data simultaneously in a limited space, making it very suitable for small and medium-sized process control stations.
functional positioning
Its main function is to:
Read: Collect current or voltage signals output by on-site sensors
Conversion: Convert analog signals into digital signals that can be processed by the controller
Output: Generate precise analog control signals based on controller instructions to drive execution devices
It belongs to a typical AI/AO combined analog module.
Channel configuration characteristics
1. Six channel design
Input and output resources are allocated as needed, enabling parallel operation of multi-channel monitoring and control.
The module supports multiple input types, such as 4-20 mA, 0-10 V (depending on system configuration).
2. Stable signal processing accuracy
Internally equipped with analog-to-digital conversion and filtering mechanisms, it can effectively reduce the impact of noise on sampling accuracy and ensure the reliability of collected data.
3. Output capability can drive on-site devices
The output channel can generate stable analog control signals, which are commonly used to regulate the control commands of valves, frequency converters, and actuators.
Electrical and Protection Design
Each channel usually has isolation and overvoltage protection to reduce mutual interference
Capable of error detection, able to identify typical signal anomalies such as open circuits and short circuits
Small temperature drift during operation, suitable for control systems that operate continuously for a long time
AEG MODICON 6051-042.23964 6模拟输入输出模块 产品展示
