AEG MODICON AS-B827-200热电偶输入模块 PDF资料
1.产 品 资 料 介 绍：
模块概述
AEG MODICON AS-B827-200 是一款热电偶输入模块，用于工业自动化系统中精确采集温度信号。该模块能够将来自各类热电偶传感器的模拟温度信号转换为控制系统可处理的数据，适用于需要温度监控和调节的生产场景。
核心功能亮点
支持多路热电偶输入，可同时采集多个温度点的数据。
内置信号调理和放大电路，确保温度测量精度和稳定性。
提供电气隔离功能，减少系统干扰，提高安全性。
可直接与 Modicon 控制器架构集成，简化安装与调试过程。
提供状态指示功能，便于现场检测和维护。
可能的技术规格
支持常用热电偶类型，如 K、J、T、E 等。
输入通道数通常为 8 路或 16 路，具体取决于模块版本。
模拟信号转换为数字信号，通过背板总线传送到主控制器。
模块带有滤波和防干扰设计，适应工业环境。
安装方式为标准机架插装，便于模块更换与系统扩展。
适用场景
生产过程中需要实时温度监控的设备，如炉窑、干燥机、加热器等。
化工、制药或食品加工等工业环境中的温度控制系统。
自动化控制系统的热量测量与调节任务。
需要多点温度采集和高精度信号处理的工业控制项目。
AEG MODICON AS-B827-200热电偶输入模块 英文介绍
Module Overview
AEG MODICON AS-B827-200 is a thermocouple input module used for precise temperature signal acquisition in industrial automation systems. This module is capable of converting simulated temperature signals from various thermocouple sensors into data that can be processed by the control system, making it suitable for production scenarios that require temperature monitoring and regulation.
Core functional highlights
Supports multiple thermocouple inputs and can simultaneously collect data from multiple temperature points.
Built in signal conditioning and amplification circuits ensure temperature measurement accuracy and stability.
Provide electrical isolation function to reduce system interference and improve safety.
It can be directly integrated with the Modicon controller architecture, simplifying the installation and debugging process.
Provide status indication function for easy on-site inspection and maintenance.
Possible technical specifications
Supports commonly used thermocouple types such as K, J, T, E, etc.
The number of input channels is usually 8 or 16, depending on the module version.
The analog signal is converted into a digital signal and transmitted to the main controller through the backplane bus.
The module is equipped with filtering and anti-interference design, suitable for industrial environments.
The installation method is standard rack insertion, which facilitates module replacement and system expansion.
Applicable scenarios
Equipment that requires real-time temperature monitoring during the production process, such as furnaces, dryers, heaters, etc.
Temperature control systems in industrial environments such as chemical, pharmaceutical, or food processing.
Thermal measurement and regulation tasks for automated control systems.
Industrial control projects that require multi-point temperature acquisition and high-precision signal processing.
AEG MODICON AS-B827-200热电偶输入模块 产品展示
