AEG MODICON AS-BDAO-216离散输出模块 PDF资料
1.产 品 资 料 介 绍：
模块概述
AEG MODICON AS-BDAO-216 是一款用于输出开关量信号的离散输出模块，可直接向现场设备发送控制指令。它适配早期 Modicon PLC 架构，能够稳定驱动各类电气执行元件，用于实现开关动作、设备启停或逻辑触发。该模块以响应快捷、结构可靠、兼容性强著称，在老系统维护与设备改造中应用广泛。
核心功能亮点
输出通道能够向现场提供明确的开关指令，适合控制电磁阀、继电器线圈、小型接触器等设备。
模块具备过载或短路保护能力，使输出回路在异常条件下不会损坏控制总线。
输出状态通过前面板指示灯直观呈现，便于现场确认设备是否已收到控制信号。
与 Modicon 800/984 系列结构兼容，可直接用于扩展老系统输出点数。
响应时间短，适合对动作时序有一定要求的机械或过程控制系统。
可能的技术规格（基于该型号系列的常见参数整理）
输出类型一般为 24V DC 或更高等级的开关量信号，具体取决于版本。
通道数量通常为 16 点，适用于中等规模的设备。
每个输出具备独立隔离或保护电路，可降低外部负载对控制器的影响。
通过机架背板总线与 CPU 或远程处理器通信，由系统统一分配输出指令。
安装方式为插装式模块，可直接在系统中更换或扩展。
适用场景示例
控制各种现场执行装置，例如电磁阀、灯指示、继电器线圈等常用设备。
用于老 Modicon 系统的输出扩展，使设备在改造时保持原有架构。
需要频繁启停或定序动作的机械控制系统，如包装、装配或输送设备。
中小型自动化流程控制中，用于将逻辑运算结果转换为实际动作指令。
AEG MODICON AS-BDAO-216离散输出模块 英文介绍
Module Overview
AEG MODICON AS-BDAO-216 is a discrete output module used for outputting switch signals, which can directly send control instructions to field devices. It is compatible with the early Modicon PLC architecture and can stably drive various electrical actuators to achieve switch actions, equipment start stop, or logic triggering. This module is known for its fast response, reliable structure, and strong compatibility, and is widely used in the maintenance and equipment renovation of old systems.
Core functional highlights
The output channel can provide clear switch instructions to the site, suitable for controlling equipment such as solenoid valves, relay coils, and small contactors.
The module has overload or short circuit protection capability, so that the output circuit will not damage the control bus under abnormal conditions.
The output status is visually displayed through the front panel indicator lights, which facilitates on-site confirmation of whether the device has received the control signal.
Compatible with Modicon 800/984 series structure, it can be directly used to expand the output points of old systems.
Short response time, suitable for mechanical or process control systems with certain requirements for action timing.
Possible technical specifications (compiled based on common parameters of this model series)
The output type is generally 24V DC or higher level switch signal, depending on the version.
The number of channels is usually 16, suitable for medium-sized equipment.
Each output has an independent isolation or protection circuit, which can reduce the impact of external loads on the controller.
Communicate with the CPU or remote processor through the rack backplane bus, and distribute output instructions uniformly by the system.
The installation method is plug-in module, which can be directly replaced or expanded in the system.
Examples of Applicable Scenarios
Control various on-site execution devices, such as solenoid valves, light indicators, relay coils, and other commonly used equipment.
Used for output expansion of the old Modicon system to maintain the original architecture of the device during renovation.
Mechanical control systems that require frequent start stop or sequential actions, such as packaging, assembly, or conveying equipment.
In small and medium-sized automated process control, it is used to convert logical operation results into actual action instructions.
AEG MODICON AS-BDAO-216离散输出模块电路板 产品展示
