AEG MODICON SIM-203 模拟分析模块 PDF资料
1.产 品 资 料 介 绍：
产品名称： AEG MODICON SIM-203 模拟分析模块
产品类型： 模拟量采集与分析模块
所属系列： AEG Modicon 工业控制系统
一、产品概述
SIM-203 是 Modicon 系统中专用于模拟量采集和基础信号分析的功能模块。可接收多路模拟输入，对信号进行转换、判断与初级处理，将处理后的数据传送至控制器，为系统提供稳定可靠的现场参数支持。
二、主要功能
多路模拟信号采集，支持电压或电流输入类型。
内置 A/D 转换电路，实现模拟量到数字量的精确转换。
支持基础信号处理，包括滤波、阈值检测、极限判断等。
提供模块运行状态指示，便于现场维护与诊断。
与 Modicon 机架总线兼容，可直接装入系统使用。
三、产品特点
采集精度高，响应稳定。
通道间具备基本隔离能力，降低信号干扰。
模块化结构，安装维护简便。
专为连续工业运行设计，可靠性强。
可作为老旧控制系统的替换模块，兼容性好。
四、典型应用
工业过程控制中的模拟量参数监测。
电力、能源设备的温度、压力、流量采集。
各类机械设备的运行状态数据分析。
发电厂、化工厂、钢铁行业等连续生产系统。
老版 Modicon PLC 系统的技术维护与改造项目。
AEG MODICON SIM-203 模拟分析模块 英文介绍
Product Name: AEG MODICON SIM-203 Simulation Analysis Module
Product type: Analog quantity acquisition and analysis module
Series: AEG Modicon Industrial Control System
1、 Product Overview
SIM-203 is a functional module specifically designed for analog signal acquisition and basic signal analysis in the Modicon system. It can receive multiple analog inputs, convert, judge and process signals, and transmit processed data to the controller to provide stable and reliable on-site parameter support for the system.
2、 Main functions
Multi channel analog signal acquisition, supporting voltage or current input types.
Built in A/D conversion circuit, achieving precise conversion from analog to digital.
Support basic signal processing, including filtering, threshold detection, limit judgment, etc.
Provide module operation status indication for easy on-site maintenance and diagnosis.
Compatible with Modicon rack bus, it can be directly installed into the system for use.
3、 Product Features
High collection accuracy and stable response.
Channels have basic isolation capabilities to reduce signal interference.
Modular structure, easy installation and maintenance.
Specially designed for continuous industrial operation, with strong reliability.
Can be used as a replacement module for old control systems, with good compatibility.
4、 Typical applications
Analog parameter monitoring in industrial process control.
Temperature, pressure, and flow collection of power and energy equipment.
Analysis of operational status data for various types of mechanical equipment.
Continuous production systems such as power plants, chemical plants, and the steel industry.
Technical maintenance and renovation project for the old Modicon PLC system.
AEG MODICON SIM-203 模拟分析模块 产品展示
