GIDINGS&LEWIS 502-03381-01直流输出板 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502-03381-01 直流输出板

产品概述

Giddings & Lewis 502-03381-01 直流输出板是一种用于数控机床和工业自动化系统的信号控制模块，主要功能是将控制系统的数字或模拟控制信号转换为直流电平输出，用于驱动执行机构、继电器、指示灯或其他外围设备。该模块是实现机床动作控制和设备联动的重要接口单元。

技术特点

• 多通道输出：支持多路直流输出，满足多点控制需求。

• 高速响应：快速将控制指令转换为输出信号，实现实时动作控制。

• 模块化设计：可直接安装在控制机架或控制柜中，便于维护和更换。

• 工业级可靠性：抗干扰、耐振动，适合复杂工业环境。

• 保护功能：具备过流、短路和过压保护，保证模块及系统安全。

应用领域

1. 数控机床
   驱动伺服或步进执行机构、继电器、刀具夹具或指示装置，实现动作控制。

2. 立式车床及复合加工中心
   输出控制信号实现多轴动作联动及辅助装置驱动。

3. 自动化生产线
   控制机械手臂、输送装置或其他执行单元的动作，实现生产线协调运作。

4. 机床改造与升级
   在老旧设备数控化改造中，实现控制信号输出，提高设备控制精度和可靠性。

5. 机器人及精密机械设备
   为机械臂或精密装置提供可靠的直流信号输出，实现动作执行与系统联动。

英文资料：

GIDINGS&LEWIS 502-03381-01 DC output board

Product Overview

Giddings&Lewis 502-03381-01 DC output board is a signal control module used for CNC machine tools and industrial automation systems. Its main function is to convert digital or analog control signals of the control system into DC level outputs, which are used to drive actuators, relays, indicator lights, or other peripheral devices. This module is an important interface unit for implementing machine tool action control and equipment linkage.

Technical Features

Multi channel output: Supports multiple DC outputs to meet multi-point control requirements.

High speed response: Quickly convert control instructions into output signals to achieve real-time action control.

Modular design: can be directly installed in the control rack or control cabinet for easy maintenance and replacement.

Industrial grade reliability: anti-interference, vibration resistant, suitable for complex industrial environments.

Protection function: It has overcurrent, short circuit, and overvoltage protection to ensure the safety of modules and systems.

Application field

CNC machine tool

Drive servo or stepper actuators, relays, tool fixtures, or indicator devices to achieve motion control.

Vertical lathe and composite machining center

Output control signals to achieve multi axis action linkage and auxiliary device driving.

Automatic production line

Control the actions of robotic arms, conveyors, or other execution units to achieve coordinated operation of the production line.

Machine tool transformation and upgrading

In the numerical control transformation of old equipment, control signal output is achieved to improve equipment control accuracy and reliability.

Robots and precision mechanical equipment

Provide reliable DC signal output for robotic arms or precision devices to achieve action execution and system linkage.
