GIDINGS&LEWIS 502-02814-08直流输入板 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502-02814-08 直流输入板

产品概述

Giddings & Lewis 502-02814-08 直流输入板是一种用于数控机床和工业自动化系统的信号采集模块，主要用于接收外部直流电平信号（如传感器、开关或安全装置的状态信号），并将其转换为控制系统可识别的数字信号，实现系统对外部事件的监控和响应。

技术特点

• 高精度信号采集：可靠读取直流信号状态，确保控制系统接收准确信息。

• 多通道输入：支持多路直流信号输入，满足多点监控需求。

• 快速响应：低延迟信号处理，实现实时控制。

• 模块化设计：可直接安装在控制机架或控制柜，便于维护与更换。

• 工业级可靠性：抗干扰、耐振动，适合重型机床及工业自动化环境。

• 保护功能：具备短路和过压保护，确保模块和系统安全。

应用领域

1. 数控机床
   接收限位开关、光电传感器、紧急停止等直流信号，实现机床安全控制和动作监控。

2. 立式车床及复合加工中心
   采集各轴位置传感器或安全装置状态，实现多轴联动和安全监控。

3. 自动化生产线
   监控传送装置、机械手臂或装配设备的状态，保证动作协调与安全运行。

4. 机床升级与改造
   在老旧设备数控化改造中，实现对直流信号的采集和数字化处理，提高系统智能化水平。

5. 机器人及精密机械设备
   用于采集传感器和限位信号，实现机械臂或精密设备的精确控制与保护。

英文资料：

GIDINGS&LEWIS 502-02814-08 DC Input Board

Product Overview

Giddings&Lewis 502-02814-08 DC input board is a signal acquisition module used for CNC machine tools and industrial automation systems. It is mainly used to receive external DC level signals (such as status signals of sensors, switches, or safety devices) and convert them into digital signals that can be recognized by the control system, enabling the system to monitor and respond to external events.

Technical Features

High precision signal acquisition: Reliable reading of DC signal status to ensure accurate information reception by the control system.

Multi channel input: Supports multiple DC signal inputs to meet multi-point monitoring requirements.

Fast response: low latency signal processing for real-time control.

Modular design: can be directly installed on the control rack or control cabinet for easy maintenance and replacement.

Industrial grade reliability: anti-interference, vibration resistant, suitable for heavy-duty machine tools and industrial automation environments.

Protection function: It has short-circuit and overvoltage protection to ensure the safety of modules and systems.

Application field

CNC machine tool

Receive DC signals such as limit switches, photoelectric sensors, emergency stops, etc., to achieve machine tool safety control and action monitoring.

Vertical lathe and composite machining center

Collect the status of position sensors or safety devices on each axis to achieve multi axis linkage and safety monitoring.

Automatic production line

Monitor the status of transmission devices, robotic arms, or assembly equipment to ensure coordinated and safe operation of actions.

Machine tool upgrade and renovation

In the numerical control transformation of old equipment, the acquisition and digital processing of DC signals are achieved to improve the level of system intelligence.

Robots and precision mechanical equipment

Used for collecting sensor and limit signals to achieve precise control and protection of robotic arms or precision equipment.
