GIDINGS&LEWIS 503-19185-01编码输入模块  PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 503-19185-01 编码输入模块

产品概述

Giddings & Lewis 503-19185-01 编码输入模块是一种用于数控机床和自动化系统的反馈信号接口模块，主要用于接收来自旋转编码器（Encoder）的位置信号或速度信号，并将其转换为控制系统可识别的标准数字信号。该模块是实现闭环控制、精确定位及多轴联动的关键组件。

技术特点

• 高精度信号处理：解析增量或绝对编码器信号，保证位置和速度反馈的准确性。

• 闭环控制支持：与伺服驱动器、执行控制板等协同，实现高精度运动控制。

• 多通道输入：可同时接收多个编码器信号，适应多轴控制需求。

• 模块化设计：便于机架安装、维护及更换。

• 工业适应性：抗干扰、耐振动，适合重型机床环境。

应用领域

1. 数控镗床、铣床
   提供主轴、工作台和刀架等轴的精确位置和速度反馈，实现高精度加工。

2. 立式车床及车铣复合中心
   协调多轴运动，实现复杂零件的多工序加工。

3. 自动化生产线
   监控机械手臂或多轴执行单元的位置，保证动作同步。

4. 机床改造与升级
   在老旧设备数控化改造中，提供编码器接口，实现运动精度提升。

5. 机器人及精密机械设备
   支持高精度机械臂或其他精密设备的闭环位置和速度控制。

产品优势

• 高精度与高稳定性：保证多轴运动的精确性和系统稳定性。

• 可靠性强：闭环反馈与抗干扰设计适应工业环境。

• 扩展性好：支持多轴、多编码器输入，满足复杂控制需求。

• 维护简便：模块化设计，便于快速更换和系统调试。

• 提升生产效率：优化反馈和运动控制，提高加工精度和产能。

英文资料：

GIDINGS&LEWIS 503-19185-01 Encoding Input Module

Product Overview

Giddings&Lewis 503-19185-01 Encoding Input Module is a feedback signal interface module used for CNC machine tools and automation systems. It is mainly used to receive position or velocity signals from rotary encoders and convert them into standard digital signals that can be recognized by the control system. This module is a key component for achieving closed-loop control, precise positioning, and multi axis linkage.

Technical Features

High precision signal processing: Analyze incremental or absolute encoder signals to ensure the accuracy of position and velocity feedback.

Closed loop control support: Collaborate with servo drives, execution control boards, etc. to achieve high-precision motion control.

Multi channel input: capable of receiving multiple encoder signals simultaneously, suitable for multi axis control requirements.

Modular design: facilitates rack installation, maintenance, and replacement.

Industrial adaptability: anti-interference, vibration resistant, suitable for heavy-duty machine tool environments.

Application field

CNC boring and milling machines

Provide precise position and speed feedback for axes such as spindle, worktable, and tool holder to achieve high-precision machining.

Vertical lathe and milling composite center

Coordinate multi axis motion to achieve multi process machining of complex parts.

Automatic production line

Monitor the position of robotic arms or multi axis execution units to ensure synchronized actions.

Machine tool transformation and upgrading

In the CNC transformation of old equipment, providing encoder interfaces can improve motion accuracy.

Robots and precision mechanical equipment

Support closed-loop position and speed control of high-precision robotic arms or other precision equipment.

Product advantages

High precision and high stability: ensuring the accuracy and system stability of multi axis motion.

Strong reliability: Closed loop feedback and anti-interference design are suitable for industrial environments.

Good scalability: Supports multi axis and multi encoder inputs to meet complex control requirements.

Easy to maintain: modular design for quick replacement and system debugging.

Improve production efficiency: optimize feedback and motion control to enhance machining accuracy and productivity.
